9.2.4.3

Adjusting the length of the legrest

PLEASE NOTE: Danger of injury due to incorrect adjustment of the footrests and legrests.
• Before and during every journey it is imperative to ensure that neither the legrests nor the
steering wheels contact the ground!
Pre-requisites:
• 1x 10 mm open-ended spanner
• Use the spanner to loosen the screw (1).
• Adjust to the desired length.
• Re-tighten the screw.
120
