Front castor tyres
Tyre pressure
Driving Characteristics
Speed
Max. tilt-resistant climbing power
Max. surmountable obstacle
height
Turning radius
Range according to ISO 7176 *** • 50 km
Dimensions
Total height
Width of the drive unit
Overall width of the seat (with
standard armrests)
Seat width 39 cm
Seat width 43 cm
Seat width 48 cm
Overall width of the seat (with
parallel sliding armrests)
Seat width 39 cm
Seat width 43 cm
Seat width 48 cm
Overall length (including
standard legrests)
Seat height without lifter
164
• 2.8 bars
• 6/9 km/h
• 11% (9°)
• 8 cm
• 74 cm
Standard Kontur
• 94 • 105
• 63 cm • 63 cm
- -
• 60 cm • 60 cm
• 64 cm • 64 cm
• 69 cm • 69 cm
- -
• 64 cm • 64 cm
• 68 cm • 68 cm
• 73 cm • 73 cm
• 134 cm • 134 cm
• 47 cm • 47 cm
• 49 cm • 49 cm
Flex
• 98
• 63 cm
-
• 60 cm
• 64 cm
• 69 cm
-
• 64 cm
• 68 cm
• 73 cm
• 134 cm
• 47 cm
• 49 cm
