Dimensions
Seat angle, electric adjustment
(wheelchair equipped with lifter)
Weight
Empty weight (with standard seat
and gearless motors) *****
Payload
Max. load
Axle loads
Max. load per axle in
the front
Max. load per axle in
the rear
* Approximately.
** Width adjustable via side section adjustment.
*** Remark: the range of an electric wheelchair is strongly dependent on external factors such as charge state of the batteries, ambient
temperature, local topography, condition of the road surface, tyre pressure, weight of the driver, manner of driving and the use of the
batteries for lighting, servos etc.
**** Measured without seat cushion
***** The actual kerb weight depends on the fittings your mobility aid has been supplied with. Every Invacare® mobility aid is weighed when
leaving the works. Please refer to the nameplate for the kerb weight (including batteries) measured.
166
Standard
• 0° ... +35°
• -10 ... +35°
Without lifter
• 165 kg
Seat depth 38, 41 cm
• 100 kg
• 230 kg
• 120 kg
Kontur
• 0° ... +35°
• -10 ... +35°
With lifter
• 189 kg
Seat depth 43 cm
• 110
Flex
• 0° ... +35°
• -10 ... +35°
Seat depth 46, 51 cm
• 120
