1.7 Mouse

This equipment supports USB1.1 mouse, so the user can operate with mouse (mouse operation is as same as WINDOWS
operating setting) to realize menu functions. It is just ok to insert the mouse with USB interface to the mouse interface in this
Mouse action Function
Right button Enter system main menu: real-time screen preview, single mouse left click
Single left click the functional menu icon, and enter menu setting page
Double mouse left
The image in a channel can be enlarged by double click real-time monitoring and playback screen, it can
click
be recovered into monitoring and multi-split image after double click again
Access to volume adjustment, color adjustment and PTZ control menu. The volume adjustment, color
adjustment and PTZ control can set only one channel, please select corresponding screen if multi-
screen mode is on prior to setting.
If you single click mouse button in volume adjustment and PTZ control:
PTZ control is available if clicking direction or "+ and -" icon;
There is a volume bar in volume control interface. Move mouse to a position and click right button, the
corresponding volume will be shown in the right side of the volume bar, click "X" to exit;
Click the left mouse
button
The operations like color adjustment can be referred to above volume adjustment.
If there are many options in the option box, click the left button and drop-down menu will be shown.
Fast forward and fast backward function can be realized by left clicking in video playback interface.
Click the left button or right button can activate the soft keyboard in input box, clicking right button can
switch English and Chinese input state; the number, symbol and English word capitalization can be
realized only by clicking.
The Chinese spell is also available via the soft keyboard input when Chinese input, its input method is
as same as remote control; left button can be used for turning page.
Click left button and move can adjust the parameters in volume adjustment and color adjustment
Mouse movement
interface, there is corresponding parameter display in right side when movement.
Click left button and move the motion box can set the dynamic detection zone in motion detection zone.
equipment.
