Ease brake calipers onto
brake disks.
with OE BMW Motorrad
Integral ABS:
The cable of the ABS
sensor could chafe
through if it comes into
contact with the brake disk.
Ensure installation of the ABS
sensor cable close to the
front suspension.
Route ABS sensor cable 7
as shown in picture.
Make sure that ABS sensor
cable is clipped into hold-
ers 8 and 9.
Install mounting screws 1
with appropriate torque.
Brake caliper on slider
tube
22 lb/ft (30 Nm)
Remove adhesive tape from
wheel rim.
Operate brakes several
times until brake pads
contact brake disk.
Remove rear wheel stand if
mounted.
Removing rear wheel
Components of the ex-
haust system can be
hot.
Do not touch hot parts of the
exhaust system.
Place motorcycle on an
auxiliary stand; BMW Mo-
torrad recommends BMW
Motorrad rear wheel stand.
Installing rear-wheel stand
( 106)
with OE Center stand:
Make sure ground is level
and firm and place motorcy-
cle on its center stand.
