Roomba Virtual Wall

The Virtual Wall emits an invisible, infrared beam up to 13 feet (~4 meters) long that Roomba
regards as a barrier and will not cross. The beam is keyhole shaped and can get up to 3 feet wide
(~1 meter). To avoid IR interference, do not place the Virtual Wall within 8 feet (2.4 meters) from
a Home Base.When turned on, the standard Virtual Wall Unit will turn off automatically after
approximately 2 hours. The batteries last about 140 hrs of operations.
Strength Setting
Power Button
IR Emitter/Force Field
IR wall beam emitter
