Draytek Vigor2760Vn Quick Start Manual page 11

Interface
PWR
I / O
Factory Reset
WLAN
ON/OFF/WPS
(Vigor 2760n and
Vigor 2760Vn only)
VDSL/ADSL
USB (1-2)
LAN (1-4)
(or WAN2)
Description
Connector for the power adapter.
Power switch. Turns the unit on or off.
Restore the default settings. Usage: Turn on the
router (ACT LED is blinking). Press gently and hold
for more than 5 seconds. When the ACT LED blinks
rapidly, release the button and the router will restart
with its factory default configuration.
WLAN ON/OFF - Press button to enable/disable.
WLAN WPS - Press this button for 2 seconds to
allow for client devices to connect through WPS.
RJ-11 connector for ADSL or VDSL line
Connector for USB storage, printer or 3G/4G
modem
RJ-45 Gigabit Ethernet connectors for local network
devices. If WAN2 (Ethernet) is enabled, LAN Port 4
becomes WAN2 (and WAN1 is disabled).
3
Vigor2760 Series Quick Start Guide
