4.5 Network connections

You can connect a number of digital devices to your multifunction display using the Network connector(s) at the rear of the unit.
A typical network of digital devices may include:
• Up to 6 Raymarine multifunction displays.
• SeaTalk hs or RayNet digital devices such as a sonar module and radar scanner.
• Ethernet IP cameras.
Note: Your multifunction display includes the following network connectors:
• e7, e7D, a65 and a67 = 1 x SeaTalk
• New c Series and New e Series (excluding the e7 and e7D) = 2 x SeaTalk
Networks requiring additional network connections will require a Raymarine network switch.
Typical SeaTalk hs network
1
hs
SeaT alk
1. Raymarine network switch.
2. Multifunction display.
3. Raymarine radar scanner.
4. Thermal camera.
Note: New a Series displays do not support connection to a thermal camera.
Network hardware
Item Part number
HS5 SeaTalk hs network A80007
switch
SeaTalk hs network E55058
switch
Cables and connections
hs
/ RayNet connector.
2
/ RayNet
hs
SeaT alk / RayNet
hs
SeaTalk / RayNet
Notes
5–port switch for
network connection
of multiple SeaTalk
devices featuring
RayNet connectors.
Equipment with
SeaTalk hs connectors
can also be connected
via suitable adaptor
cables.
8–port switch for
network connection
of multiple SeaTalk
devices.
hs / RayNet connectors.
2
hs
SeaT alk / RayNet
Item
SeaTalk hs crossover
coupler
hs
Ethernet Coupler
hs
3
Part number Notes
E55060 Enables direct
connection of
SeaTalk
to smaller systems
where a switch is
not required. Also
enables the connection
of SeaTalk
to an HS5 SeaTalk
network switch (in
conjunction with a
RayNet to RJ45 cable).
R32142 Enables direct
connection of ethernet
or SeaTalk
to smaller systems
where a switch is not
required. Also enables
the connection of
ethernet or SeaTalk
devices to an HS5
SeaTalk
switch (in conjunction
with a RayNet to RJ45
cable).
4
D12251-1
hs devices
hs devices
hs
hs devices
hs
hs network
43
