10.1 Using Man Overboard (MOB)
functions
Man overboard
If you lose a person or object overboard, you can use the Man
Overboard (MOB) function to mark the position that the vessel
was at when the MOB function was activated.
The MOB function is available at all times, regardless of which
application is running. MOB can be set to Dead Reckoning
or Position mode. Dead Reckoning mode will take into
consideration the effects of wind and tides. This usually provides
a more accurate course. Position mode does not take these
factors into account.
To obtain a MOB position, your multifunction display must have
a GPS position fix. If you're using dead reckoning, heading and
speed data must also be available.
When MOB is activated:
• An audible MOB alarm is sounded.
• An MOB alarm dialog box is displayed.
• The system sends MOB alarms to other Raymarine
equipment.
• The active chart application is changed to a low-detail 2D
view, with an initial range of 15 m (50 ft). Motion mode is set
to Auto Range.
• The active radar application range is changed to 230 m (760
ft).
• All Goto and Follow functions are disabled in all applications.
Navigation to any active waypoint is stopped and any existing
navigation function is cancelled.
• If position or heading and speed information is available a
MOB waypoint is placed at the current vessel position in any
application that is capable of showing waypoints and vessel
position.
• MOB data is displayed in the databar, replacing the existing
data.
• MOB data is displayed on the homescreen, replacing the
status icons.
• As the vessel moves away from the MOB position a dotted
line is displayed, joining the MOB position with the vessel's
position.
When the MOB alarm is cancelled:
• MOB data is removed from the relevant applications.
• The chart application motion mode is reset.
• The chart is centered on the vessel and pitch / rotation set
to default.
• GOTO and route functions are restored.
• The databar mode is reset.
• A MOB normal mode signal is sent to any instrument on
SeaTalk.
Activating the man overboard (MOB) alarm
— New c Series / New e Series
On a New c Series or New e Series display you can use the
WPT (MOB) button to activate the MOB alarm
1. Press and hold the WPT / MOB button for 3 seconds.
Activating the man overboard (MOB)
alarm — New a Series
On a New a Series display you can use the on-screen WPT
(MOB) icon to activate the MOB alarm
1. Press and hold the on-screen WPT / MOB icon for 3 seconds.
Silencing the MOB alarm.
The MOB alarm can be silenced by following the steps below.
With a MOB alarm active:
106
1. Select Ok on the MOB alarm dialog.
The alarm will be silenced but remains active.
Cancelling the man overboard (MOB)
alarm — New a Series
To cancel a MOB alarm and resume normal operation follow the
steps below:
1. Press and hold the on-screen WPT / MOB icon for 4 seconds.
The MOB alarm is cancelled and normal operation is
resumed.
Cancelling the man overboard (MOB) alarm
— New c Series and New e Series
To cancel a MOB alarm and resume normal operation follow the
steps below:
1. Press and hold the WPT / MOB button for 4 seconds.
The MOB alarm is cancelled and normal operation is
resumed.
New a Series / New c Series / New e Series
