Listing Non-Default Bsr Configuration Settings - HP ProCurve 6200yl Multicast And Routing Manual

PIM-SM (Sparse Mode)
Displaying PIM-SM Data and Configuration Settings
4-60

Listing Non-Default BSR Configuration Settings

The show running command includes the current non-default BSR configura­
tion settings on the router.
ProCurve(config)# show running
Running configuration:
.
.
.
ip routing
snmp-server community "public" Unrestricted
vlan 1
.
.
.
vlan 120
.
.
.
ip multicast-routing
router rip
exit
router pim
bsr-candidate
bsr-candidate source-ip-vlan 120
bsr-candidate priority 1
rp-candidate
rp-candidate source-ip-vlan 120
rp-candidate group-prefix 224.0.0.0 240.0.0.0
rp-candidate hold-time 150
exit
vlan 120
ip rip 120.10.10.2
ip pim-sparse
ip-addr any
exit
exit
.
.
.
Figure 4-21. Example of Non-Default BSR Configuration Listing
Example of Non-Default BSR
Candidate Configuration in the
Router's Running Configuration
Note: priority appears only if it is
configured to a non-default value.
