ProCurve# show ip ospf virtual-link
OSPF Virtual Interface Status
Transit AreaID
--------------- --------------- --------------- ---------------
10.3.16.0
10.3.16.0
Figure 5-24. Example of Output for Show IP OSPF Virtual-Link
Table 5-14. CLI Display of OSPF Virtual Link Information
Field Description
Transit Area ID Area ID of transit area for the virtual link.
Neighbor Router Router ID of the virtual neighbor.
Authentication none or simple (same as for normal interface).
Interface State The state of the virtual link to the virtual neighbor. The possible values are:
• DOWN – the routing switch has not yet found a route to the virtual neighbor.
• P2P – (point-to-point) the routing switch has found a route to the virtual neighbor. Virtual links

Displaying OSPF Virtual Link Information

To display OSPF virtual link information, enter show ip ospf virtual-link at any
CLI level.
Neighbor Router Authentication
10.0.8.33
10.0.8.36
Syntax: show ip ospf virtual-link [area < area-id > | < ip-address >]
This display shows the following information.
are "virtual" serial links, hence the point-to-point terminology.
Notice from the syntax statement that you can get OSPF virtual link informa­
tion for a specific area or a specific IP address.
none
none
IP Routing Features
Configuring OSPF
Interface State
P2P
P2P
