- Page 1 HVN61/81 Induction Hob Manual for Installation, Use and Maintenance Customer Care Department • The Group Ltd. • Harby Road • Langar • Nottinghamshire • NG13 9HY T : 01949 862 012 F : 01949 862 003 E : service@cda.eu W : www.cda.eu...
-
Page 2: Appliance Information
Appliance information: Please enter the details on the appliance rating plate below for reference, to assist CDA Customer Care in the event of a fault with your appliance and to register your appliance for guarantee purposes. Appliance Model... - Page 3 2004/108/EC. Parts intended to come into contact with food conform to 89/109/EC. IMPORTANT INFORMATION FOR CORRECT DISPOSAL OF THE PRODUCT IN ACCORDANCE WITH EC DIRECTIVE 2002/96/EC. At the end of its working life, the product must be taken to a special local authority waste collection centre or to a dealer providing appliance recycling services.
- Page 4 To avoid interference between your hob and a pacemaker, your pacemaker must be designed and programmed in compliance with the regulations that apply to it. As such, CDA guarantee only that our product is compliant. With regard to the compliance of the pacemaker or any potential incompatibility, you should obtain information from the manufacturer or your attending physician.
- Page 5 Important • Do not use the hob if the glass surface is cracked or damaged to prevent the risk of electric shock. Disconnect it from the power supply. • Ensure that the power cable of a connected electrical appliance near the hob is not in contact with the cooking zones. Important: Please refer to page 13 for information on configuring the power consumption mode correctly.
- Page 6 Cooking on Induction The principle of induction cooking is based on magnetic effect. When you put your cookware on an induction zone and switch it on, the electronic boards in the hob produce induced currents in the base of the cookware and instantly raise its temperature. This heat is then transferred to the food inside the cookware.
-
Page 7: Using Your Hob
Using your Hob HVN61FR Zones: HVN81FR Zones 1. Front left 2.8 kW 180 mm 5. Front left 2.2 kW 160 mm 2. Back left 2.8 kW 180 mm 6. Back left 3.1 kW 210 mm 3. Back right 3.1 kW 210 mm 7. - Page 8 Using your Hob To switch the zone on • Touch the key for the zone required. The zone display will flash 0 and the hob will beep to confirm the hob is on. Please note: If a power level is not set within five seconds, the zone will switch off automatically.
- Page 9 • It is possible to adjust the direct power keys if necessary. To do so, when the hob is switched off, touch the direct power key for approximately five seconds until the hob beeps and the display shows the current power level. Then touch the keys until the zone display shows the required power level.
- Page 10 Please note: Using the boost or precook function on one zone automatically limits the power level available to the other zone on the same side. If you wish to use several pans at the same time, try to use zones on opposite sides.
- Page 11 Please note: • The timer will only count down when the cookware is on the zone. • The timer will count down in minutes, and then in seconds for the last minute. • At the end of the set time, the zone will switch off, the timer will flash 0 and the hob will beep for approximately 20 seconds.
- Page 12 Touch the key at any time during cooking. The timer display will flash the number of minutes the zone has been on the current power level for five seconds. To set the remaining cooking time Touch the key at any time during cooking. Whilst the timer display is flashing, touch the key to set the total cooking time required.
-
Page 13: Safety Features
Safety Features The childlock The hob is equipped with a childlock to lock the controls. This can be used when the hob is off or during cooking To set the childlock Touch the key for approximately three seconds until the LED above the childlock key illuminates and the hob beeps to confirm the child- lock is switched on. -
Page 14: Residual Heat Indicators
Residual Heat Indicators The hob is equipped with residual heat indicators to warn when any of the zones are still hot to the touch after cooking. An H will flash in the relevant zone display after cooking until the zone is at a safe temperature to touch. -
Page 15: Overflow Protection
Overflow Protection The hob is equipped with a sensor that will switch off the hob, and display the symbol in the zone display in any of the following situations: • Overflow from the pan spills over the control keys • A damp cloth is placed over the control keys •... -
Page 16: Efficient Use Of Your Hob
Efficient Use of your Hob The hob is equipped with zones of different sizes, designed to accommodate most shapes and sizes of pan. For best results, only use pans with flat bottoms and choose an appropriate zone depending on the size of the pan. The most efficient use of the hob is shown below, where the pan and zone are correctly chosen. -
Page 17: Care And Maintenance
Care and Maintenance Always disconnect the appliance from the power supply before undertaking any cleaning or maintenance. Important: • Steam cleaners must not be used when cleaning this appliance. • You should use a non-abrasive cleaner to clean the hob top. Any abrasive cleaner (including Cif) will scratch the surface and could erase the control panel markings. -
Page 18: Troubleshooting
2. Check that the mains supply has not been switched off. 3. Check that the fuse in the spur has not blown. In the event of a fault with the hob, please advise CDA Customer Care of any fault code shown on the display... - Page 19 IMPORTANT - PLEASE NOTE: In the event of any breakage, crack or cracking – even minimal – of the vitroceramic glass, immediately disconnect your appliance to prevent a risk of electric shock and contact CDA Customer Care.
-
Page 20: Fitting The Hob
Fitting the Hob Unpacking the hob: Take care not to lose or mishandle any parts. Fitting position of the hob: This appliance must be installed a minimum of 50mm from any back wall and a minimum of 180mm away from any adjacent vertical surfaces, e.g. - Page 21 recommended) (Fig.5). If the instructions supplied with the hood dictate that the hood must be installed at a height greater than 600mm, then that height is the minimum required. Wall furniture requirements: The minimum height of any cabinet immediately above the hob is 900mm.
-
Page 22: How To Install The Hob
How to install the hob: Overall dimensions of the hob: HVN61FR: Width: 580 mm Depth: 510 mm HVN81FR: Width: 770 mm Depth: 510 mm Worktop cut-out dimensions: HVN61FR: Width: 560 mm Depth: 490 mm HVN81FR: Width: 750 mm Depth: 490 mm 1. - Page 23 min 4mm Above an oven Fig.4 Fig.5 580/770 560 / 750 Fig.6...
-
Page 24: Mains Electricity Connection
Mains Electricity Connection Warning! this appliance must be earthed We recommend that the appliance is connected by a qualified electrician, who is a member of the N.I.C.E.I.C. and who will comply with the I.E.E. and local regulations. This appliance is intended to be connected to fixed wiring and is not suitable for connection to a 13a plug or 13a supply. - Page 25 • The marking of the current rating of the fuse or circuit breaker protecting this appliance should be marked on the socket outlet. • Assembly and electrical connection should be carried out by specialised personnel. • When installing this product we recommend you seek the help of another individual.
- Page 28 Please contact our Customer Care Department, or for Service on the details below. Customer Care Department • The Group Ltd. • Harby Road • Langar • Nottinghamshire • NG13 9HY T : 01949 862 012 F : 01949 862 003 E : service@cda.eu W : www.cda.eu...
