EasyCoder 3400e Bar Code Label Printer User's Manual
The minimum number of required image bands is dependent upon the print speed and
the complexity of the label. Labels that contain numerous fields with different rotations,
graphics, or combinations of these formatting options may require a higher number of
image bands.
To set the number of image bands, use PrintSet or the IPL command. For help, see the
PrintSet online help or the IPL Programming Reference Manual.
The maximum number of image bands available for use is 20 bands. The minimum
number of image bands available is 2.
To optimize the number of image bands for your print speed
1. Set the image band setting at the lowest number (2).
2. Print a label at the desired speed.
3. Return to the original print speed and increase the original number of image bands
If the printer still aborts and reprints at the highest image band setting, you may be
trying to optimize at a print speed that is too high for your label format. Try optimizing
the number of image bands at a lower print speed or add an expansion DRAM SIMM.
To print very complex labels at high speeds, you must allocate enough image bands to
completely image the label before printing. Allocate one band for each inch of label
length. By doing this, you can print at any speed. However, there may be a considerable
delay between labels.
5-10
If the label prints, the image band setting is optimal. You do not need to perform
any more adjustments.
If the number of image bands is too low, the printer aborts the label before printing
is completed and attempts to reprint the label at the slowest speed (2 ips) with the
highest number of image bands (20). You need to continue with Step 3.
one at a time.
Continue to increase the number of image bands until the printer prints a label
correctly.
