EasyCoder 3400e Bar Code Label Printer User's Manual
Loading Media for Fanfold Printing
11. Press Feed/Pause to advance one label through the printer and out the label opening
Note: If the yellow Empty/Pause LED does not go out, press Feed/Pause a second time
and then reload the media and try again if the Empty/Pause LED still does not go out.
Note: For your convenience, refer to the label with directions for loading media. This
label is located on the inside of the media cover.
1-8
Head lift
lever
Lower
media guide
Edge
Supply
guide
Supply
roll
roll
retainer
post
in the front cover. The printer is now ready to print the configuration test label. The
yellow Empty/Pause LED goes out.
Media access
slot
O
Fanfold
media
3XXXU.006
