Appendix 2 Media Specifi cations

Media Roll Size

68
Core
Diameters: 38-40 mm (1.5 inches) or 76.2 mm (3 inches)
Width: Must not protrude outside the media.
The media must be wound up on the core in such a way
that the printer can pull the end free.
Roll
Max. diameter:
- Position 1
- Position 2
- Position 3
Max. width:
Min. width (standard):
Min. width (Quick-Load):
The maximum recommended media thickness is 175µm (0.007
inches). Thicker media may be used, but print quality will be
reduced. The stiffness is also important and must be balanced
against thickness to maintain print quality.
Media rolls to be loaded inside the printer should be wound with
the printable side facing outwards.
The media supply must not be exposed to dust, sand, grit, etc.
Any hard particles, however small, can damage the printhead.
152 mm
213 mm
203 mm
60 mm
25 mm
40 mm
Intermec EasyCoder F2 – User's Guide
(6.00 inches)
(8.38 inches)
(8.00 inches)
(2.36 inches)
(1.00 inches)
(1.57 inches)
