Rear Panel Connectors
1
100-240V
0.5A MAX
1
50/60 Hz
Figure 2-2 — Rear panel of MPS 112
1
100-240V
0.5A MAX
1
50/60 Hz
Figure 2-3 — Rear panel of MPS 112CS
1
2
3
4
5
6
7
8
9
10
11
2-4
MPS Series • Installation
2
3
6
VIDEO
VGA
1
3
2
3
4
OUT
2
4
S-VIDEO
4
5
2
3
6
VIDEO
VGA
1
3
2
3
4
OUT
(S-VIDEO)
2
4
4
5
AC power — Standard AC power connector for a power source of
100 – 240 VAC, operating at 50/60 Hz
Video input group — Four female BNC connectors for composite video input
(numbered 1 through 4)
Video output — One female BNC connector for composite video output
S-video input group — Four female 4-pin mini DIN connectors for S-video
input (numbered 1 through 4)
S-video output — One female 4-pin mini DIN for S-video output
VGA input group — Four female 15-pin HD connectors for VGA input
(numbered 1 through 4)
VGA output — One female 15-pin HD connector for VGA output
RS-232 remote — One female 9-pin D connector for a host computer or a
controller using Extron's Simple Instruction Set (SIS) or Windows-based
control software
(VGA) audio input group — Four 3.5 mm, female, stereo mini jacks for audio
input. See Audio input and output in this chapter.
To reduce crosstalk, it is recommended that you either terminate all the VGA
audio input jacks or avoid switching to a VGA audio input that has no device
connected to it.
(VGA) audio output — One 3.5 mm, female, stereo mini jack for audio output
from the VGA group input. See Audio input and output in this chapter.
Microphone input (MPS 112) — 6.3 mm mono microphone jack connection
for an external microphone
8
9
10
14
15
(VGA)
(S-VIDEO)
RS-232
OUT
L
1
3
MIC IN
1
2
3
4
R
2
4
OUT
AUDIO
7
11
8
9
10
14
15
(VGA)
(S-VIDEO)
RS-232
OUT
L
1
3
PHANTOM
1
2
3
4
POWER
MIC IN
R
2
4
OUT
AUDIO
7
12
13
16
17 18
(VIDEO)
MPS 112
OUT
1
2
3
4
OUT
PROG OUT
16
17
19
(VIDEO)
MPS 112CS
OUT
1
2
3
4
OUT
PROG OUT
L
R
