Spare parts

10 Spare parts
Below is a list of the spare parts for this boiler. Look up the position number in the exploded view drawing on the next two pages for the
illustration. Spare parts may be ordered from Buderus.
Pos. Description
Casing 24/30 kW
1
Casing 45/60 kW
2 Casing latches left (2 pc)
3 Casing latches right (2 pc)
Casing seal 24/30 kW
4
Casing seal 45/60 kW
5 Wall mounting bracket
Back panel 24/30 kW
6
Back panel 45/60 kW
7 Cap air vent
9 Seal ring Ø 3"
10 Seal ring Ø 80 mm
11 Flue gas collector
12 Oval seal
Heat exchanger 24/30 kW
13 Heat exchanger 45 kW
Heat exchanger 60 kW
14 Heat exchanger baffle 24/30 kW
Seal condensate collector 24/30 kW
15 Seal condensate collector 45 kW
Seal condensate collector 60 kW
Condensate collector + sealing 24/30 kW
16 Condensate collector + sealing 45 kW
Condensate collector + sealing 60 kW
17 Clamp
18 Sensor NTC
19 Revision set air vent **
20 Sight glass
Burner box 24/30 kW
21 Burner box 45 kW
Burner box 60 kW
22 Safety sensor
Seal burner 24/30 kW
23 Seal burner 45 kW
Seal burner 60 kW
Gas/air distribution plate 24/30 kW
24 Gas/air distribution plate 45 kW
Gas/air distribution plate 60 kW
Orifice plate 24/30 kW
25
Orifice plate 60 kW
Burner 24/30 kW
26 Burner 45 kW
Burner 60 kW
27 Gas-air inlet
28 Seal fan
29 Ionization electrode
30 Hot surface ignitor
31 Shield hot surface ignitor
32 Mounting plate
33 Seal mounting plate (5 pc)
128 Logamax plus GB142-24/30/45/60 - We reserve the right to make any changes due to technical modifications!
Product No. Pos. Description
7099988
7099901
7099039
7099038
7098752
7098798
7098364
7099001
7099903
7100250
77470s
7096475
7098857
7098858
7746900159
7746900160
7746900161
7098828
7098834
7098838
67900522
7098840
7098844
67900521
7098848
7100136
7098822
7098575
7099057
7098875
67900525
78194
7098916
7098920
67900526
7100922
7098926
67900527
7100920
7746900120
7099003
7098932
67900528
7099004
7099023
78195
7099006
7100229
7098852
7098850
** not shown in exploded views
Air inlet pipe; 24/30 kW
34
Air inlet pipe; 45/60 kW
35 Seal Ø50 mm (5 pc)
Venturi 24/30 kW
36 Venturi 45 kW
Venturi 60 kW
37 Seal set (4 pc)
38 Fan
39 Gas control valve
40 Gas supply pipe GB142 USA
41 Spring (5 pc)
42 Seal 2x16x22 (5 pc)
L.P. Orifice Ø 3.35 - 24/30 kW
0-10,200 ft
L.P. Orifice Ø 3.40 - 24/30 kW
4,001-10,200 ft
L.P. Orifice Ø 4.15 - 45 kW
0-10,200 ft
N.G. Orifice Ø 4.45 - 24/30 kW
0-10,200 ft
N.G. Orifice Ø 4.50 - 30 kW
4,001-10,200 ft
N.G. Orifice Ø 4.55 - 24 kW
4,001-10,200 ft
43
N.G. Orifice Ø 5.40 - 45 kW
0-10,200 ft
L.P. Orifice Ø 5.40 - 60 kW
0-10,200 ft
L.P. Orifice Ø 5.45 - 60 kW
4,001-10,200 ft
N.G. Orifice Ø 5.55 - 45 kW
4,001-10,200 ft
N.G. Orifice Ø 7.50 - 60 kW
0-10,200 ft
N.G. Orifice Ø 7.65 - 60 kW
4,001-10,200 ft
44 Condensate trap, part of pos. 88
45 Seal condensate trap (5 pc)
Supply pipe CH; 24/30/45 kW
47
Supply pipe CH; 60 kW
Return pipe 24/30/45 kW
48
Return pipe 60 kW
49 Pressure sensor **
50 Bottom plate
51 Transformer 120V
52 Grommet
53 External connection board
54 External connection board cover
55 Fuse 5 AF slow blow
56 UBA cover
57 UBA 3 - 120V
Product No.
7099024
7099023
7099058
7099020
7099925
7099931
7099021
78184
7099025
76685
7100549
7098778
76687
7746901353
7746901355
7099016
7746901421
7746901354
76690
76690
7746901357
7746901356
76686
7746901358
8718600689
7100742
75990
75991
709965
709945
8718600019
7099049
78191
7099050
7099042
7099046
73904s
7099047
7099707
