ProForm HYBRID TRAINER User Manual page 13

15. The Console (16) requires four AA batteries (not
included); alkaline batteries are recommended.
Do not use old and new batteries together or
alkaline, standard, and rechargeable batter-
ies together. IMPORTANT: If the Console has
been exposed to cold temperatures, allow it
to warm to room temperature before insert-
ing batteries. Otherwise, you may damage
the console displays or other electronic
components.
Remove the battery cover from the back of the
Console (16), and insert batteries into the battery
compartment. Make sure to orient the bat-
teries as shown by the diagram inside the
battery compartment. Then, reattach the bat-
tery cover.
16. Have a second person hold the Console (16)
near the Console Bracket (79). Connect the
wires on the Console to the Main Wire Harness
(45) and to the Pulse Wires (68).
Insert the excess wire into the Console Bracket
(79) or into the Console (16).
Tip: Avoid pinching the wires. Attach the
Console (16) to the Console Bracket (79) with
four M4 x 16mm Screws (47).
17. Attach the Water Bottle Holder (27) to the
Upright (13) with two M4 x 16mm Screws (47).
15
16
16
16
Avoid pinching
the wires
17
47
13
Battery
Cover
45
79
68
27
13
47
