7. Hold the Console Post (73) near the Upright (13)
as shown. Insert the Main Wire Harness (45)
upward through the Console Post.
8. Tip: Avoid pinching the Main Wire Harness
(45). Slide the Console Post (73) onto the
Upright (13) and hold it in place.
Next, insert the Axle (80) into the Console Post
(73) and into the Upright (13). Center the Axle.
Then, tighten the Console Knob (9) with an M10
Curved Washer (39) into the Console Post (73)
and into the Upright (13).
7
8
Avoid pinching
the Main Wire
Harness (45)
9
45
13
80
73
39
45
13
73
9
