Chapter 7
Setup Mode
Entering
Setup Mode
at Installation
Navigating in
Setup Mode
42
To enter the Setup Mode, press the < Setup> key on the printer's
built-in keyboard. The following message in the display window
indicates that you have entered the Setup Mode:
SETUP:
COMMUNICATION
While going through the setup procedure, you are guided by texts
in the printer's display. You can step between setup parameters,
acknowledge displayed values, select or type new values etc. using
some of the keys on the printer's keyboard.
-
1
/. Left, right, up, and down refer to the overviews later in this
chapter.
Intermec EasyCoder F2 – Installation & Operation IPL Version, Ed. 1
Move one menu to the left on the same
1
level .
Move one menu to the right on the same
1
level .
Move up one level or scroll back in a stack
1
of options .
Move down one level or scroll forward in a
1
stack of options .
Enter numeric values.
Specify negative values (leading position).
Clear erroneously entered values.
Acknowledge and move to next menu.
Print test labels in the Testprint menus.
Exit the Setup Mode.
(Can be used anywhere in the Setup Mode.)
