Overview
System Memory
Chipset
Expansion Slots
Serial Port
Parallel Port
Floppy Interface
IDE Interface
USB Interface
PS/2 Mouse
Keyboard
RTC and Battery
BIOS

1.2 APM Suspend to Hard Drive

Suspend to Hard Drive saves your current work (system status, memory and
screen image) into hard disk, and then the system can be totally power off.
Next time, when power is on, you can resume your original work directly from
hard disk within few seconds without go through the Win95 booting process
and run your application again. If your memory is 16MB, normally, you need to
reserve at least 16MB HDD space to save your memory image. Note that you
have to use VESA compatible PCI VGA (AOpen PV70/PT70), Sound Blaster
compatible sound card and sound driver that supports APM (AOpen
AW32/AW35) for Suspend to Hard Drive to work properly. Of course, we
recommend choosing AOpen products for best compatibility.
To use Suspend to Hard Drive:
1-4
168-pin DIMM x3, maximum 768MB EDO or 384
SDRAM.
Intel 82440LX AGPset
ISA x2, PCI x4 and AGP x1
Two serial ports UART 16C550 compatible, and the
3rd UART for IR function.
One parallel port supports standard parallel port (SPP),
enhanced parallel port (EPP) or extended capabilities
port (ECP).
Floppy interface supports 3.5 inches drives with
720KB, 1.44MB or 2.88MB format or 5.25 inches
drives with 360KB, 1.2MB format.
Dual-channel IDE interface support maximum 4 IDE
hard disks or CDROM, mode 4, bus master hard disk
drives and Ultra DMA/33 mode hard drives are also
supported.
Two USB ports supported by USB bracket, the BIOS
also supports USB driver to simulate legacy keyboard.
Mini-Din PS/2 mouse connector onboard.
Mini-Din PS/2 keyboard connector onboard.
RTC within Intel PIIX4E chipset. Lithium (CR-2032)
battery is an option, no battery is needed if power cord
is plugged.
AWARD Plug-and-Play, 2M bit Flash ROM BIOS.
