Jumpers:
JP12:
JP14:
JP28:
Connectors:
PS2:
KB:
COM1:
COM2:
PRINTER:
PWR2:
USB:
FDC:
IDE1:
IDE2:
CPUFAN1:
CDUFAN2:
FAN:
IrDA:
PANEL:
CD-IN:
MODEM-CN:
WOM:
WOL:
2.2 Jumpers
With the help of Celeron PPGA VID signal and SMbus, this motherboard is
jumper-less design.
Enable/Disable Sound
Clear CMOS
KB/MS-WKUP
PS/2 mouse connector
PS/2 keyboard connector
COM1 connector
COM2 connector
Printer connector
ATX power connector
USB connector
Floppy drive connector
IDE1 primary channel
IDE2 secondary channel
CPU fan connector
CPU fan connector
Housing Fan Connector
IrDA (Infrared) connector
Front panel (Multifunction) connector
CD-audio connector
Mono in (Pin 1-2) and Mic out (Pin 3-4)
Wake On Modem connector
Wake On LAN connector
