8.2

Code to Isolate

This method restricts only those User Codes with
the Code to Isolate priority level to isolate zones.
If any User Code has this priority level, the
method of standard isolating does not function.
How to Isolate a Zone
1. Press the [*] button followed by your User
Code and the [*] button again to enter the
Isolating Mode (for example, [*2580*]). Three
beeps sound and the STAY indicator flashes.
2. Enter the zone number (1 to 8), followed by
the [*] button (for example, [1*] = Zone 1, [2*]
= Zone 2).
Each zone to be isolated has a corresponding
zone indicator that flashes. If you selected an
incorrect zone to be isolated, enter the
incorrect zone number again followed by the
[*] button.
Repeat Step 2 if more than one zone is to be
isolated until all zones to be isolated are
selected.
3. Press the [#] button after all selected zones are
isolated.
Two beeps sound and the system returns to
the disarmed state.

Table 11: Fault Indicators

Zone Indicator Fault Description
1 System Fault
2 RF Low Battery
3 Zone Tamper Alarm
4 Sensor Watch Fault
5 RF Sensor Watch
6 Communication Fail
Bosch Security Systems, Inc. | 12/08 | F01U089456-02
9.
If a fault occurs, the FAULT or MAINS indicators
flash and the codepad beeps once every min.
If the AC MAINS supply fails, the MAINS
indicator flashes until the AC MAINS supply is
restored. Pressing the [#] button once
acknowledges the fault and stops the codepad
from beeping once every min.
How to Determine the Type of System Fault
To determine which system fault occurred, enter
Fault Analysis Mode by following the steps below:
1. Hold down the [5] key until two beeps sound.
The FAULT indicator remains steady and the
STAY and AWAY indicators flash in unison.
A zone indicator displays the type of fault that
occurred (for example, Zone 1 = System
Fault). Refer to Table 11 on page 12 for the list
of possible system faults.
2. To further determine the type of fault
condition, press and hold down the key that
corresponds to the zone indicator displayed.
For example, if Zone 1 displayed System
Fault, press and hold the [1] key to display
which system fault occurred.
3. To exit Fault Analysis Mode and return to the
disarmed state, press the [#] key. The FAULT
indicator continues to display and the codepad
stops sounding once a min.
Hold Down Button Zone Indicator
1
2 1 to 8
3 1 to 8
4 1 to 8
5 1 to 8
6

Fault Analysis Mode

Fault Condition
1 Battery Fail
2 Date and Time
3 RF Receiver Fail
4 Horn Speaker Fail
5 Telephone Line Fail
6 EEPROM Fail
7 AUX Power Supply Fail
8 AC Fail
Zones 1 to 8 RF Low Battery
Zones 1 to 8 Tamper Alarm
Zones 1 to 8 Sensor Watch Fail
Zones 1 to 8 RF Sensor Watch Fail
1 Receiver 1 Fail
2 Receiver 2 Fail
EN | 12
