Codepad Alarms; Codepad Duress Alarm; Codepad Panic Alarm; Codepad Fire Alarm - Bosch ICP-CC488 User Manual

ICP-CC488 | User's Guide | 7.
7.

Codepad Alarms

7.1

Codepad Duress Alarm

A codepad duress alarm is used as a silent hold-up
alarm. This only occurs when the number 9 is added
to the end of any valid user code being used to
disarm the system (for example, [25809#]). A duress
alarm is only useful if your system is reporting back
to a monitoring station or pocket pager. Domestic
reporting (such as a mobile phone) cannot decipher
which type of alarm occurred.
Figure 7: ICP-CP508W LED Codepad Showing
Audible Alarm Buttons
7.2

Codepad Panic Alarm

An audible alarm activates when you press the [1]
and [3] keys or the [*] and [#] keys simultaneously.
Contact your installer to disable the codepad panic
alarm function or to silence the codepad panic alarm.
7.3

Codepad Fire Alarm

The horn speaker emits a distinct fire sound when
you press the [4] and [6] keys simultaneously.
Contact your installer to disable the codepad fire
alarm function or to silence the codepad fire alarm.
7.4

Codepad Medical Alarm

An audible codepad Medical Alarm activates when
you press [7] and [9] simultaneously. Contact your
installer to disable the codepad medical alarm
function or to silence the codepad medical alarm.
Bosch Security Systems, Inc. | 12/08 | F01U089456-02
Codepad Alarms
7.5
Codepad tamper restricts the number of times an
invalid user code can be used in an attempt to
operate the system. When the number of incorrect
code attempts equals the number programmed by
your installer, the system activates an alarm
condition. If reporting back to a security monitoring
station, the system sends an Access Denied report.
To shutdown and lockout a codepad for a period of
time (0 sec to 150 sec), ask your installer to program
this function.
8.
Use isolating zones to manually disable one or more
zones before arming the system. Once a zone is
isolated, you can access that zone during the armed
state without activating an alarm.
For example, you need to isolate a zone because
before arming the system a PIR detector may be
false alarming, or you need to leave a pet inside a
particular zone while away.
Isolating zones is performed by one of two methods.
Method two is optional and only allows those user
codes programmed by your installer to have access
to isolate zones.
8.1
Standard isolating allows all operators to isolate
zones without knowing a valid user code.
How to Isolate a Zone
1. Press the [*] button twice to enter the Isolating
Mode.
Three beeps are heard and the STAY indicator
flashes.
2. Enter the zone number (1 to 8), followed by the
[*] button (for example, [1*] = Zone 1, [2*] =
Zone 2).
Each zone to be isolated has a corresponding
zone indicator that flashes. If you selected an
incorrect zone to be isolated, enter the incorrect
zone number again followed by the [*] button.
Repeat Step 2 if more than one zone is to be
isolated until all zones to be isolated are selected.
3. Press the [#] button after all selected zones are
isolated.
Two beeps are heard and the system returns to
the disarmed state.
Codepad Tamper Alarm (Access
Denied)

Isolating Zones

Standard Isolating

EN | 11
