Schwinn 420 Elliptical - 2010 Model Owner's Manual page 10

LCD Display
AA1 Program Display
AA2 Pulse
AA3 Watts
AA4 Calories
Program Display
The Program Display shows the name of the program selection and the dot-matrix area shows the course profile for the program.
Each column in the profile shows one interval (1/40 of the total program time). The higher the column, the higher the resistance
level and/or speed for that interval. The flashing column shows your current interval.
Pulse
The Pulse display field shows the heart rate in beats per minute (BPM) from the heart rate monitor (HRM).
Consult a physician before you start an exercise program. Stop exercising if you feel pain or tightness in your chest,
become short of breath, or feel faint. Contact your doctor before you use the machine again. Use the values calculated or
measured by the machine's computer for reference purposes only.
Watts
The WATTS display field shows the power that you are producing at the current resistance level (1 horsepower = 746 watts).
Calories
The CALORIES display field shows the estimated calories that you have burned during the exercise. If no calorie goal is set up
for the current workout program, the display value starts at zero and counts forward until the end of the workout. If the workout
has a calorie goal, the display starts at the preset value and counts down to zero.
Distance
The DISTANCE display field shows the distance count (miles or km) in the workout. If no distance goal is set up for the current
workout program, the display value starts at zero and counts forward until the end of the workout. If the workout has a distance
goal, the display starts at the preset value and counts down to zero.
AA5 Distance
AA6 Speed
AA7 Time
