Transmitter Terminal Reference
Figure A-7 Model 2400S transmitters with DeviceNet
With display
Figure A-8 Model 2400S transmitters with PROFIBUS-DP
With display
Installation and Use Manual
3.237
G/S
Service port
(RS-485/B)
Service port
(RS-485/A)
Service port
(RS-485/B)
Service port
(RS-485/A)
Without display
Service port
(RS-485/B)
Service port
(RS-485/A)
Without display
Service port
(RS-485/B)
Service port
(RS-485/A)
