Transmitter Terminal Reference
Figure A-6 Model 2400S transmitters with analog outputs
(with display, cover removed)
HART clips HART clips
Note: The user interface shown here is equipped with a display. On models without a display, the
HART clips and service port clips are located in the same position on the user interface.
68
User interface
Service port
(RS-485/B)
Service port
(RS-485/A)
Outputs wiring compartment
(user interface removed)
2 (–)
1 (+)
®
ProLink II Software for Micro Motion
®
Transmitters
