Emerson Network Router User Manual page 18

Installation and Setup
Figure 2-2 HART/Bell 202 temporary connection to RFT9739 field-mount and RFT9712 transmitters
Prongs
Transmitter
Notes:
• Add R1 if necessary to bring the total resistance within 250–1000 Ω.
Figure 2-3 HART/Bell 202 temporary connection to RFT9739 rack-mount transmitters
HART jack
R1
Notes:
• Add R1 if necessary to bring the total resistance within 250–1000 Ω.
12
or
R1
Bell 202 cable (not included)
or
®
ProLink II Software for Micro Motion
USB plug
Bell 202 signal
converter
USB plug
Bell 202 signal
converter
®
Transmitters
