Transmitter Configuration, Characterization, and Calibration
Figure 5-5 D1 and D2 density calibration
Close shutoff valve
downstream from sensor
52
Fill sensor with D1 fluid
ProLink
Calibration
Density cal - Point 1
Enter density of D1 fluid
Do Cal
Calibration in Progress
light turns red
Calibration in Progress
light turns green
Close
Fill sensor with D2 fluid
ProLink
Calibration
Density cal - Point 2
Enter density of D2 fluid
Do Cal
Calibration in Progress
light turns red
Calibration in Progress
light turns green
Close
®
ProLink II Software for Micro Motion
®
Transmitters
