PRI Facilities

Call by Call Service Table

When a call is placed on a Call by Call B-channel group, a specific service is
selected, depending on the match between the dialed digits and the table
entries. A service must be specified, otherwise the entry is ignored. The Call
by Call table can contain up to 10 entries; each entry can contain up to 10
patterns, each with a maximum of eight digits. If a dialed number matches
two patterns, the longer pattern takes precedence. That is, 212555 matches
both 212555 and 212; however, the longer pattern is deemed the matching
pattern. In addition to patterns, the Call by Call table can specify from 0
through 8 digits to be deleted (the default is 0).
If the last entry in the table is empty (no pattern is specified), this entry is used
as a default and matches any pattern and type of call.
Summary: Call by Call Service Table
Programmable by
Mode
Idle Condition
Planning Form
Factory Setting
Valid Entries
Inspect
Copy Option
Console Procedure
System manager
All
Not required
Form 3b, Incoming Trunks – DS1 Connectivity (100D
Module)
Not applicable
Pattern
— up to eight digits
— voice, data, both
Call
— AT&tT Toll, Local, Misc.
Service
Delete — 0-8
No
No
To specify Patterns:
LinesTrunks
Service Patterns
Drop Dial pattern
Exit Exit
PRI OutgoingTbl
Dial list no.
Enter Exit
Call by Call Service Table
CBC
Enter
Exit
8-23
