Hot Swap Drive Cage Upgrade Install Instructions (optional)
b. If you are installing a six-drive SAS/SATA hot swap drive cage:
Warning: It is critical that you connect the SAS/SATA data cables correctly from the
Note: The SAS/SATA cables are labeled to correspond with each drive. Make sure to
The SAS/SATA connectors are laid out as follows on the SAS/SATA backplane.
Figure 87. Layout of Cable Connectors on the SAS/SATA Backplane (Backplane without
70
SAS/SATA backplane to your server board or RAID Controller card.
Failure to do so may result in data loss.
connect the cables correctly to avoid confusion later.
B
A
C
D E
A. Power cable
B. Data Cable
C. IPMB
D. SES (not available in AXX6DRV3GEXP)
expander shown)
Intel® Entry Server Chassis SC5299-E UP/DP/WS/BRP User Guide
HDD 1
HDD 3
HDD 2 HDD 5
HDD 0 HDD 4
AF00450
