Intel SE7501WV2 - Server Chassis - SR2300 Product Manual

Server chassis subassembly product guide
Hide thumbs Also See for SE7501WV2 - Server Chassis - SR2300:
Table of Contents

Advertisement

Quick Links

Download this manual See also: Configuration Manual
Intel
®
Server Chassis SR2300
Subassembly Product Guide
®
A Guide for Technically Qualified Assemblers of Intel
Identified Subassemblies/Products
A86100-003
Order Number:

Advertisement

Table of Contents
loading

Related Manuals for Intel SE7501WV2 - Server Chassis - SR2300

Summary of Contents for Intel SE7501WV2 - Server Chassis - SR2300

  • Page 1 Intel ® Server Chassis SR2300 Subassembly Product Guide ® A Guide for Technically Qualified Assemblers of Intel Identified Subassemblies/Products A86100-003 Order Number:...

  • Page 2: Important Safety Instructions

    No license, express or implied, by estoppel or otherwise, to any intellectual property rights is granted by this document. Except as provided in Intel's Terms and Conditions of Sale for such products, Intel assumes no liability whatsoever, and Intel disclaims any express or implied warranty, relating to sale and/or use of Intel products including liability or warranties relating to fitness for a particular purpose, merchantability, or infringement of any patent, copyright or other intellectual property right.

  • Page 3: Table Of Contents

    Contents 1 Chassis Description..................7 What Your Kit Includes......................7 Items You Must Purchase Separately..................7 Feature Summary ........................8 System Components ...................... 8 Chassis Front Panel and Peripheral Bays..............9 Chassis Back I/O Ports and Features ................10 Front Panel Controls and Indicators................11 Peripherals ..........................
  • Page 4 WARNUNG: Deutsch ......................78 AVVERTENZA: Italiano......................80 ADVERTENCIAS: Español ....................82 D Warranty......................85 ® Limited Warranty for Intel Chassis Subassembly Products..........85 Extent of Limited Warranty....................85 Warranty Limitations and Exclusions ..................86 Intel Server Chassis SR2300 Subassembly Product Guide...
  • Page 5 Limitations of Liability ....................86 How to Obtain Warranty Service................... 87 Telephone Support....................... 87 Returning a Defective Product ..................88 Figures Figure 1. System Components....................8 Figure 2. Chassis Front......................9 Figure 3. Chassis Back ......................10 Figure 4. Controls and Indicators ..................11 Figure 5.
  • Page 6 Tables Table 1. Control Button Functions .................. 12 Table 2. LED Indicator Status..................12 Table 3. Power Usage Worksheet 1................71 Table 4. Power Usage Worksheet 2................72 Intel Server Chassis SR2300 Subassembly Product Guide...

  • Page 7: Chassis Description

    One 480 W SSI PFC non-redundant power supply or a 500 W 1+0 SSI PFC redundant power supply with one module and one blank Two PCI riser cards for use with the Intel Server Board SE7500WV2 or SE7501WV2 Three system fans...

  • Page 8: Feature Summary

    PCI add-in card (accessory to N. Hard drive bay (one of six, accessory to system) system) G. Riser card assembly (low-profile) O. Backplane board H. Processor air duct Front panel board Figure 1. System Components Intel Server Chassis SR2300 Subassembly Product Guide...

  • Page 9: Chassis Front Panel And Peripheral Bays

    Chassis Front Panel and Peripheral Bays To access the system controls and peripherals when a front bezel is installed, grasp the bezel and gently pull it towards you until it unsnaps from the chassis. OM14081 Chassis handles (2) Drive bay (1-inch) C.

  • Page 10: Chassis Back I/O Ports And Features

    N. Video connector G. Power supply module, redundant O. USB connector 1 (system accessory)* H. Power supply module, primary* *480 Watt redundant power supply shown. Your power supply may be different. Figure 3. Chassis Back Intel Server Chassis SR2300 Subassembly Product Guide...

  • Page 11: Front Panel Controls And Indicators

    Front Panel Controls and Indicators Shown with optional DVD/CD-ROM drive/floppy disk drive installed. OM14083 Figure 4. Controls and Indicators NIC 2 activity LED G. ID button Power button H. Reset button C. Power/sleep LED USB Connector D. Fixed disk drive status LED NMI button System status LED Video Connector...

  • Page 12: Table 1. Control Button Functions

    BIOS clears it. If the system is not powered down normally, it is possible that the Power LED will be blinking at the same time that the System Status LED is off due to a failure or configuration change that prevents the BIOS from running. Intel Server Chassis SR2300 Subassembly Product Guide...

  • Page 13: Peripherals

    Peripherals The chassis provides external bays for peripherals that can be purchased separately and added to the system. The following describes the available options. OM14084 Hard drive bays (6) Flex bay (1) DVD/CD-ROM drive/floppy disk drive module Tape drive Hard disk drive Figure 5.

  • Page 14: Flex Bay

    The system fans are mounted in a fan module located in the middle of the chassis to pull cooling air through the chassis. The power supply contains a single fan for cooling. Intel Server Chassis SR2300 Subassembly Product Guide...

  • Page 15: Chassis Security

    Chassis Security To help prevent unauthorized access to the system’s peripherals and control panel, install the optional front bezel, which provides a key lock. The chassis also includes a preinstalled intrusion switch for the top access cover that can be monitored by server management software. When the cover is opened, the switch, located on the front panel board, transmits a signal to the Baseboard Management Controller (BMC) on the server board, where server management software processes the signal.
  • Page 16 Intel Server Chassis SR2300 Subassembly Product Guide...

  • Page 17: Assembling The System

    2 Assembling the System Before the server chassis SR2300 can be installed for use, you must assemble the hardware components that make up your particular system. Additionally, you will want to add any peripherals and add-in cards purchased for the system. The following procedures help guide you through this assembly process and create your desired system configuration.

  • Page 18: Installation/Assembly Safety Instructions

    Sharp pins on printed circuit assemblies Rough edges and sharp corners on the chassis Hot components (like processors, heat sinks, and power supply modules) Damage to wires that could cause a short circuit Intel Server Chassis SR2300 Subassembly Product Guide...

  • Page 19: Checking The Power Cord

    Only a technically qualified person should integrate and configure the server. Read all caution and safety statements in this document before performing any of the instructions. See also Intel Server Boards and Server Chassis Safety Information on the Resource CD and/or at http:\\support.intel.com.
  • Page 20 WARNING Do not open the power supply. Hazardous voltage, current and energy levels are present inside the power supply. Refer servicing of the power supply to qualified technical service personnel. Intel Server Chassis SR2300 Subassembly Product Guide...

  • Page 21: Installing System Components

    Installing System Components Remove the Cover 1. While pressing the blue latch button (A) with your left thumb, slide the top cover back using the heel of your right hand on the blue pad. NOTE A non-skid surface or a stop behind the chassis may be needed if attempting to remove the top cover on a flat surface.

  • Page 22: Remove The Processor Air Duct

    Remove the Processor Air Duct Lift the processor air duct out of the chassis. OM14583 Figure 7. Removing the Processor Air Duct Intel Server Chassis SR2300 Subassembly Product Guide...

  • Page 23: Remove The Riser Cards

    Remove the Riser Cards 1. Insert your finger in the plastic loop. On riser card (A), also grasp the opposite end at (C). 2. Pull straight up and remove the riser card from the chassis. 3. Discard the protective blocks. OM14087 Figure 8.

  • Page 24: Remove The Fan Module

    4. While pushing on the tab, lift up on the module to clear the retention stub. 5. Slide the module towards the power supply until it comes free. 6. Lift the fan module out of the chassis. OM14088 Figure 9. Removing the Fan module Intel Server Chassis SR2300 Subassembly Product Guide...

  • Page 25: Install The Server Board

    Install the Server Board CAUTION Do not install any server board support bumpers in the SR2300 chassis. System components must be installed in the order presented below. If installed in a different order, component damage may occur. 1. Ensure that the insulator sheet is seated securely over the standoffs, is laying flat on the chassis floor, and that the edge of the sheet is seated below the studs in the rear chassis wall.

  • Page 26: Figure 10. Mounting The Server Board Se7500Wv2/Se7501Wv2

    OM14090 Figure 10. Mounting the Server Board SE7500WV2/SE7501WV2 Intel Server Chassis SR2300 Subassembly Product Guide...

  • Page 27: Figure 11. Installing The Processor Air Dam

    6. Install processors and memory, following the directions on the Quick Start User’s Guide for SE7500WV2 or SE7501WV2. 7. If you only install one processor, you must install the processor air dam. a. Attach processor retention piece (B) to the server board (C) using the provided screws (A).

  • Page 28: Routing Cables

    To server board auxiliary power connector from supply power supply To server board primary power connector Serial cable from server board to knockout on from power supply back of chassis Figure 12. Cable Routing Intel Server Chassis SR2300 Subassembly Product Guide...

  • Page 29: Figure 13. Connecting The Main Power Cable

    Connect Power Cables 1. Verify that the P6 backplane power cable is routed from the power supply to the backplane board and is connected to the white 6-pin connector. 2. Connect the main server board power cable to the white 24-pin connector on the server board. Firmly press the two connectors together until they are fully seated.

  • Page 30: Figure 14. Installing The Fan Module

    OM14577 Figure 14. Installing the Fan module 5. Connect the fan power cables to the server board (Figure 15). OM14586 Figure 15. Connecting Fans to the Server Board Intel Server Chassis SR2300 Subassembly Product Guide...

  • Page 31: Figure 16. Connecting The Flex Circuit Cable

    Connect Flex Circuit Cable 1. Remove the flex circuit cable from the cable bag in the accessory kit. Connect the end marked “P1-Motherboard” to the floppy/front panel/IDE connector on the server board. Route the cable to the backplane board and connect the other cable end to the matching connector on the backplane.

  • Page 32: Figure 18. Installing The Flex Circuit Retention Clip

    1. Connect the auxiliary power cable to the 8-pin auxiliary power connector on the server board (A). 2. Connect the signal cable to the 5-pin signal connector on the server board (B). OM14585 Figure 19. Connecting the Auxiliary Power Cables Intel Server Chassis SR2300 Subassembly Product Guide...

  • Page 33: Figure 20. Installing The Processor Duct

    Finish Cable Routing 1. Connect the USB cable to the USB connector on the front panel. Route the cable along the top of the fan module and connect it to the server board. Make sure the cable does not lay on top of the corner of the backplane or it will get damaged when you install the top cover.

  • Page 34: Installing Peripherals

    Peripherals and add-in cards are not included in your system and must be purchased separately. The following sections describe how to install PCI add-in cards, hard disk drives, a DVD/CD-ROM drive/floppy disk drive, and a tape drive. Intel Server Chassis SR2300 Subassembly Product Guide...

  • Page 35: Installing A Pci Card On A Riser Card

    Installing a PCI Card on a Riser Card The riser card nearest the chassis sidewall (see Figure 24, B, on page 37) supports three Low Profile (LP) PCI add-in cards. The riser card on the chassis centerline (see Figure 24, A, on page 37) supports three full-length, full-height PCI add-in cards or three LP cards (an LP card must be equipped with a standard full-height PCI mounting bracket).

  • Page 36: Figure 23. Installing A Full-Length Pci Card In A Riser Card

    OM14097 Figure 23. Installing a Full-Length PCI Card in a Riser Card Intel Server Chassis SR2300 Subassembly Product Guide...

  • Page 37: Installing The Riser Cards On The Server Board

    Installing the Riser Cards on the Server Board 1. Align the riser card connector with the server board slot. 2. Firmly press the riser card straight down until it is fully seated in the server board slot. Make sure the tabs on the rear retention bracket are aligned with the holes in the chassis. 3.

  • Page 38: Installing A Hard Drive

    4. Store the air baffle for future reinstallation in the event you must operate your server without a drive in one of the bays. OM14099 Figure 25. Removing an Air Baffle from a Drive Carrier Intel Server Chassis SR2300 Subassembly Product Guide...

  • Page 39: Figure 26. Attaching The Drive To The Carrier

    5. Remove the hard drive from its wrapper and place it on an anti-static surface. 6. Set any jumpers and/or switches on the drive according to the drive manufacturer’s instructions. 7. With the drive circuit-side-down (Figure 26, A), position the connector end (E) so that it is facing the back of the carrier (B).

  • Page 40: Installing A Dvd Drive/Fdd Or Cd-Rom Drive/Fdd Module

    Installing a DVD drive/FDD or CD-ROM drive/FDD Module Your server does not come with a DVD drive, CD-ROM drive or floppy disk drive. As an accessory, Intel offers slim-line DVD drive/FDD and CD-ROM drive/FDD modules that you may purchase and install in the flex bay.

  • Page 41: Finishing Installation

    Finishing Installation Installing a Serial A port in the Rear I/O Using a standard DH-10 to DB-9 COM cable, you may install a Serial A port in the opening provided in the rear I/O (see Figure 3, C, on page 10). Connect the other end to the COM 1 serial port header on the server board (see the documentation that shipped with your server board).

  • Page 42: Install The Bezel

    Install the Bezel Place the bezel between the chassis handles and push it toward the front of the chassis until it snaps into place. OM14108 Figure 29. Installing the Bezel Intel Server Chassis SR2300 Subassembly Product Guide...

  • Page 43: Installing The System In A Rack

    3 Installing the System in a Rack Your SR2300 chassis comes equipped with a rack mount kit that can be configured for front-mount, mid-mount, or 4-post racks. An optional slide rail kit may be purchased separately. Each kit contains instructions for installation into a rack or cabinet. If you need additional copies, the order numbers are: SR1200 and SR2300 Rail Kit Installation Guide—A61347-003 SR1200 and SR2300 Bracket Kit Installation Guide—A61346-004...
  • Page 44 You may want to calculate the BTU/hr more accurately for your configuration. An extra 500 BTU/hr over many systems would translate into a large error calculating air conditioning capacity. Intel Server Chassis SR2300 Subassembly Product Guide...

  • Page 45: Working Inside Your Server

    4 Working Inside Your Server This chapter describes how to replace components in your server after it has been set up. All references to left, right, front and rear are based on the reader facing the front of the chassis. Tools and Supplies Needed Antistatic wrist strap (recommended) Safety: Before You Remove the Cover...

  • Page 46: Warnings And Cautions

    Warnings and Cautions Read all caution and safety statements in this document before performing any of the instructions. See also Intel Server Boards and Server Chassis Safety Information on the Resource CD and/or at http:\\support.intel.com. These warnings and cautions apply whenever you remove the chassis cover to access components inside the server.

  • Page 47: Replacing Components

    Replacing Components Replacing a Hard Drive CAUTION To allow proper airflow and cooling during operation, all drive bays must contain either a carrier/drive or a carrier with air baffle installed. 1. Before removing the cover to work inside the system, observe the safety guidelines on page 45. 2.

  • Page 48: Figure 31. Removing A Hard Drive From A Carrier

    8. Install the new drive in the carrier and the carrier/drive into the drive bay (see “Installing a Hard Drive” on page 38). 9. Reinstall a carrier/air baffle in any bays where you are not reinstalling a carrier/drive. Intel Server Chassis SR2300 Subassembly Product Guide...

  • Page 49: Replacing A Dvd/Cd-Rom Drive/Fdd Module

    Replacing a DVD/CD-ROM drive/FDD Module CAUTION A DVD/CD-ROM drive/FDD module is NOT hot swappable. Before replacing it, you must first take the server out of service, turn off all peripheral devices connected to the system, turn off the system by pressing the power button, and unplug the AC power cord from the system or wall outlet.

  • Page 50: Replacing A Pci Add-In Card

    9. Insert the riser card connector in the server board slot while aligning the tabs on the rear retention bracket with the holes in the chassis. 10. Firmly press the riser card straight down until it is seated in the server board slot. Intel Server Chassis SR2300 Subassembly Product Guide...

  • Page 51: Figure 33. Removing The Low-Profile Pci Riser Card

    OM14112 Figure 33. Removing the Low-Profile PCI Riser Card Working Inside Your Server...

  • Page 52: Figure 34. Removing The Full-Length Pci Riser Card

    OM14113 Figure 34. Removing the Full-Length PCI Riser Card Intel Server Chassis SR2300 Subassembly Product Guide...

  • Page 53: Replacing A 500 Watt Power Supply Module

    Replacing a 500 Watt Power Supply Module The 500 Watt redundant power supply system consists of the power supply bay and either one or two power supply modules. The optional second module provides a redundant, 1+1 system. CAUTION If you do not have the second, redundant power supply module, you must take the server out of service before replacing the single module.

  • Page 54: Replacing A Power Supply Cage

    11. At the fan end of the power supply, remove the screw (C) that attaches the power supply to the standoff in the chassis floor. OM14115 Figure 36. Replacing a Power Supply Cage Intel Server Chassis SR2300 Subassembly Product Guide...
  • Page 55 12. Lift the fan end of the power supply above the chassis standoff and slide it toward the front of the server (D). Lift the power supply out of the chassis (E). 13. Place the new power supply in the chassis and slide it to the rear as far as it will go. 14.

  • Page 56: Installing A Redundant Fan

    8. Slide the module towards the power supply until it comes free. 9. Lift the fan module out of the chassis. OM14088 Figure 37. Removing the Fan module 10. Remove the fan blank from the fan module. OM14587 Figure 38. Removing the Fan Blank Intel Server Chassis SR2300 Subassembly Product Guide...

  • Page 57: Figure 39. Installing The New Fan

    11. Connect the new fan’s cable to the connector on the fan module. 12. Insert the top of a new fan into the fan module and rotate the bottom in until tab (B) locks it in place. OM14613 Figure 39. Installing the New Fan 13.

  • Page 58: Replacing The Fan Module

    13. Make sure the USB cable is routed along the top of the fan module. 14. Connect the flex circuit cable to the backplane. 15. Install the flex circuit cable retention clip. 16. Install the full-height PCI riser card. 17. Replace the chassis cover. Intel Server Chassis SR2300 Subassembly Product Guide...

  • Page 59: Replacing A Backplane Board

    Replacing a Backplane Board 1. Before removing the cover to work inside the system, observe the safety guidelines on page 45. 2. Remove the cover from the chassis. 3. Remove all hard drives and peripherals from their bays. 4. Remove the full-height PCI riser card assembly. 5.

  • Page 60: Replacing A Front Panel Board

    6. Install the new board in the chassis being careful to insert the LED light pipes into the front panel holes. 7. Secure the board to the chassis with the thumbscrew. 8. Plug the USB and backplane cables back into the front panel board. 9. Replace the chassis cover. Intel Server Chassis SR2300 Subassembly Product Guide...

  • Page 61: Replacing A Server Board

    Replacing a Server Board 1. Before removing the cover to work inside the system, observe the safety guidelines on page 45. 2. Disconnect all cables from the rear I/O of the chassis. 3. Remove the cover from the chassis. 4. Remove the PCI riser cards. 5.
  • Page 62 15. Cable the new server board to the other system components. 16. Install the fan module. 17. Install the PCI riser cards. 18. Replace the chassis cover. 19. Connect any cables removed from the rear I/O of the chassis. Intel Server Chassis SR2300 Subassembly Product Guide...

  • Page 63: A Regulatory And Certification Information

    A Regulatory and Certification Information WARNING You must adhere to the assembly instructions in this guide to ensure and maintain compliance with existing product certifications and approvals. Use only the described, regulated components specified in this guide. Use of other products / components will void the UL Listing and other regulatory approvals of the product, and will most likely result in noncompliance with product regulations in the region(s) in which the product is sold.

  • Page 64: Product Regulatory Compliance Markings

    FCC Marking (Class A) Canada EMC Marking (Class A) Japan VCCI Marking (Class A) BSMI Certification Number Taiwan BSMI Marking (Class A) Russia GOST R Marking Korea RRL MIC Mark China Compulsary Certification Intel Server Chassis SR2300 Subassembly Product Guide...

  • Page 65: Electromagnetic Compatibility Notices

    This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. Intel Corporation 5200 N.E. Elam Young Parkway Hillsboro, OR 97124-6497...

  • Page 66: Ices-003 (Canada)

    (VCCI) from Information Technology Equipment. If this is used near a radio or television receiver in a domestic environment, it may cause radio interference. Install and use the equipment according to the instruction manual. Intel Server Chassis SR2300 Subassembly Product Guide...

  • Page 67: Bsmi (Taiwan)

    3. Name of Certification Recipient: Intel Corporation 4. Date of Manufacturer: Refer to date code on product 5. Manufacturer / Nation : Intel Corporation / Refer to Country of Origin Marked on Product Regulated Specified Components To maintain the UL listing and compliance to other regulatory certifications and/or declarations, the following regulated components must be used, and conditions adhered to.
  • Page 68 Intel Server Chassis SR2300 Subassembly Product Guide...

  • Page 69: B Equipment Log And Worksheets

    B Equipment Log and Worksheets Equipment Log Use the blank equipment log provided here to record information about your system. You will need some of this information when you run the SSU. Manufacturer Name and Item Model Number Serial Number Date Installed Chassis Server Board...
  • Page 70 Equipment Log (continued) Manufacturer Name and Item Model Number Serial Number Date Installed Hard Disk Drive 7 DAT Tape Drive Intel Server Chassis SR2300 Subassembly Product Guide...

  • Page 71: Current Usage

    Current Usage Calculating Power Usage The total combined power consumption for your configuration must be less than 500W, with any combination of loads not to exceed maximum current on any one channel as defined in Table 1. The combined power consumption on 5 V and 3.3 V should not be more then 150W. Use the two worksheets in this section to calculate the total used by your configuration.

  • Page 72: Worksheet, Total Combined Power Used By The System

    ________ W Total Combined Wattage ________ W CAUTION Do not overload: As an overall current usage limitation on the power supply, do not exceed a combined power output of 250W for all DC outputs. Intel Server Chassis SR2300 Subassembly Product Guide...

  • Page 73: C Safety Warnings

    C Safety Warnings Read all caution and safety statements in this document before performing any of the instructions. See also Intel Server Boards and Server Chassis Safety Information on the Resource CD and/or at http:\\support.intel.com. WARNING: English (US) AVERTISSEMENT: Français...

  • Page 74: Warning: English (Us)

    Do not operate the system with the chassis covers removed. After you have completed the six SAFETY steps above, you can remove the system covers. To do this: Remove and save all screws from the covers. Remove the covers. continued Intel Server Chassis SR2300 Subassembly Product Guide...
  • Page 75 WARNING: English (continued) For proper cooling and airflow, always reinstall the chassis covers before turning on the system. Operating the system without the covers in place can damage system parts. To install the covers: Check first to make sure you have not left loose tools or parts inside the system. Check that cables, add-in boards, and other components are properly installed.

  • Page 76: Avertissement: Français

    Une fois TOUTES les étapes précédentes accomplies, vous pouvez retirer les panneaux du système. Procédez comme suit: Retirez toutes les vis des panneaux et mettez-les dans un endroit sûr. Retirez les panneaux. suite Intel Server Chassis SR2300 Subassembly Product Guide...
  • Page 77 AVERTISSEMENT: Français (suite) Afin de permettre le refroidissement et l’aération du système, réinstallez toujours les panneaux du boîtier avant de mettre le système sous tension. Le fonctionnement du système en l’absence des panneaux risque d’endommager ses pièces. Pour installer les panneaux, procédez comme suit: Assurez-vous de ne pas avoir oublié...

  • Page 78: Warnung: Deutsch

    Schalten Sie das System niemals ohne ordnungsgemäß montiertes Gehäuse ein. Nachdem Sie die oben erwähnten ersten sechs SICHERHEITSSCHRITTE durchgeführt haben, können Sie die Abdeckung abnehmen, indem Sie: Entfernen Sie alle Schrauben der Gehäuseabdeckung. Nehmen Sie die Abdeckung ab. Fortsetzung Intel Server Chassis SR2300 Subassembly Product Guide...
  • Page 79 WARNUNG: Deutsch (Fortsetzung) Zur ordnungsgemäßen Kühlung und Lüftung muß die Gehäuseabdeckung immer wieder vor dem Einschalten installiert werden. Ein Betrieb des Systems ohne angebrachte Abdeckung kann Ihrem System oder Teile darin beschädigen. Um die Abdeckung wieder anzubringen: Vergewissern Sie sich, daß Sie keine Werkzeuge oder Teile im Innern des Systems zurückgelassen haben.

  • Page 80: Avvertenza: Italiano

    Dopo aver seguito i sei passi di SICUREZZA sopracitati, togliere le coperture del telaio del sistema come seque: Togliere e mettere in un posto sicuro tutte le viti delle coperture. Togliere le coperture. continua Intel Server Chassis SR2300 Subassembly Product Guide...
  • Page 81 AVVERTENZA: Italiano (continua) Per il giusto flusso dell’aria e raffreddamento del sistema, rimettere sempre le coperture del telaio prima di riaccendere il sistema. Operare il sistema senza le coperture al loro proprio posto potrebbe danneggiare i componenti del sistema. Per rimettere le coperture del telaio: Controllare prima che non si siano lasciati degli attrezzi o dei componenti dentro il sistema.

  • Page 82: Advertencias: Español

    No ponga en marcha el sistema si se han extraído las tapas del chasis. Después de completar las seis instrucciones de SEGURIDAD mencionadas, ya puede extraer las tapas del sistema. Para ello: Extraiga y guarde todos los tornillos de las tapas. Extraiga las tapas. continúa Intel Server Chassis SR2300 Subassembly Product Guide...
  • Page 83 ADVERTENCIAS: Español (continúa) Para obtener un enfriamiento y un flujo de aire adecuados, reinstale siempre las tapas del chasis antes de poner en marcha el sistema. Si pone en funcionamiento el sistema sin las tapas bien colocadas puede dañar los componentes del sistema. Para instalar las tapas: Asegúrese primero de no haber dejado herramientas o componentes sueltos dentro del sistema.
  • Page 84 Intel Server Chassis SR2300 Subassembly Product Guide...

  • Page 85: D Warranty

    Product or to refund the then-current value of the Product. In no event will Intel be liable for any other costs associated with the replacement or repair of Product, including labor, installation or other costs incurred by buyer and in particular, any costs relating to the removal or replacement of any product soldered or otherwise permanently affixed to any printed circuit board.

  • Page 86: Warranty Limitations And Exclusions

    Limitations of Liability Intel’s responsibility under this, or any other warranty, implied or expressed, is limited to repair, replacement or refund, as set forth above. These remedies are the sole and exclusive remedies for any breach of warranty.

  • Page 87: How To Obtain Warranty Service

    How to Obtain Warranty Service To obtain warranty service for this Product, you may contact Intel or your authorized distributor. North America & Latin America To obtain warranty repair for the product, please go to this website to obtain instructions: http://support.intel.com/support/motherboards/draform.htm...

  • Page 88: Returning A Defective Product

    Returning a Defective Product Before returning any product, call your authorized dealer/distribution authority. Intel Server Chassis SR2300 Subassembly Product Guide...
