Point Source Series Speakers
2-Way SP-Series
The SP Series II Point Source is an innovative
2-way component system that offers
mounting options for the high frequency
driver positioning flexibility in order to better
meet installation requirements and achieve
optimal sound. Woofers feature a new Kevlar
composite for increased power handling and
the external crossovers employ premium
components.
Sound improvements
The improved power handling capability of ECLIPSE
Point Source Series Speakers and the detachable
tweeter option allows them to be more versatile to
better suit a car's interior in achieving the maximum
performance. ECLIPSE subwoofers can also be used
for greater low frequency impact, blending easily with
the sonic signature of these speakers.
An ideal solution
Specifically designed to function as self-contained
speakers that represent the easiest way to drastically
upgrade an in-car system, ECLIPSE Point Source
Speakers are available in configurations to suit
virtually any car. With a distinctive high-performance
appearance, the many advantages these speakers have
raise them above conventional replacement speakers.
• 1˝ titanium hard dome tweeter
• Low mass, low distortion Kevlar-PMI cone
•Neodymium tweeter magnet
• Detachable tweeter
• Grilles and Adaptors included
• Woofer, bullet diffuser for tweeter height extension
• Tweeter relocation kit (flush/surface mount kit)
Configuration Style
Woofer Size
Tweeter Size
Max. Power Handling
RMS Power handling
Sound Pressure Level
Frequency Response
Fs
Magnet Size
Mounting Depth
Voice Coil DCR (Ω)
SP6900
6 × 9˝ 2-Way Point Source
• RMS power handling: 90W
• Max. power handling: 270W
SP5700
5 × 7˝ / 6 × 8˝ 2-Way Point Source
• RMS power handling: 55W
• Max. power handling: 165W
Point Source
Direct speaker replacement
for factory-installed speakers.
Point Source w/ Extended Tweeter
For installations where the speaker
is mounted some distance behind
the grille, the supplied tweeter
stand-off spacer can be added to
extend the tweeter for better high
frequency dispersion.
SP6900
6 × 9˝
1˝
270W
90W
88dB
45 — 40,000Hz 85 — 40,000Hz
45Hz
24oz
3.5˝
3.6
SP6500
• RMS power handling: 60W
• Max. power handling: 180W
SP5000
• RMS power handling: 50W
• Max. power handling: 150W
Point Source
Detached Tweeter
The speaker can be
detached into woofer and
tweeter components so
that the woofers can be
installed in doors while
tweeters can be installed
closer to windows and
other positions such as
the dashboard.
SP6500 SP5700
5 × 7˝/ 6 × 8˝
6-1/2˝
1˝ 1˝
180W 165W
60W 55W
87dB 88dB
90 — 40,000Hz
85Hz 90Hz
12oz 12oz
2-1/4˝ 2-3/8˝
3.6 3.6
6-1/2˝ 2-Way Point Source
5-1/4˝ 2-Way Point Source
Tweeters can be installed flush or
mounted on dashboards and other
locations as separate housings are
provided.
SP5000
5-1/4˝
1˝
150W
50W
84.5dB
105 — 40,000Hz
105Hz
10oz
2-1/4˝
3.6
