AVN6600/AVN5495/AVN5500 + MRE-700W
For the above-listed AVN products, adding the
RAS-100 AV Matrix enables putting together
an ideal rear seat entertainment system with
full routing and switching capabilities.
Program material signals routed from
the AVN6600 to the RAS-100.
DVD Player
Input 1
Input 2
AVN6600
(Video)
Output 2
Program material from 2 sources seen on 2 monitors.
HDR105
HD Radio Tuner Unit
Dimensions (W × H × D)
6-15/16˝ × 1-7/16˝ × 6-5/16˝
175 × 36.5 × 160mm
BEC105
Rear View Camera
Rear view camera-ready
The BEC105 optional rear camera can be
connected to the AVN units to facilitate parking.
Routing program material signals from the RAS-100
through the AVN6600.
Output 1
MRE-700
AVN6600
MRE-700
Program material from 2 sources seen on 3 monitors.
SIR-ECL1
ECLIPSE COMPATIBLE
SIRIUS SATELLITE RADIO TUNER
Dimensions (W × H × D)
4-15/16˝ × 1-7/16˝ × 4-3/16˝
125 × 35 × 105mm
CH3083
8-Disc CD Changer with
Magazine Unit
MRE-700
RAS-100
WHP-100
DVD Player
Output 2
Input 1
MRE-700
Output 1
Input 2
Output 3
GAME
MRE-700
RMC105
Wireless Remote
MRE-700
WHP-100
Recommended options
®
iPod
SIRIUS Satellite Radio
HD Radio
TV Tuner
CD Changer
Rear view camera
TVR105
TV Tuner Unit
Dimensions (W × H × D)
5-15/16˝ × 1-3/16˝ × 4-3/16˝
150 × 30 × 105.2mm
MDV-06D
2006 Version Update Navi Disc
For: AVN5435 and AVN2454.
Includes Street Map data.
MDV-06D data compiled as
of December 2004.
*For connection details of each unit, please see p18 – p19.
