Eclipse AVN7000 Brochure page 31

SYSTEMS
ECLIPSE subwoofer systems are constructed
from sturdy wood, carefully assembled and
well-damped for a tight bass. Finished in
attractive and durable vinyl, these subwoofer
systems are ready for final installation.
Featuring a configuration specifically designed for the
installation space requirements of trucks, SUVs and similar
vehicles, the SW5124BX incorporates a special low-profile
bass driver that saves space and still delivers a massive low
frequency sound.
SW6124BXD
12˝× 2 Subwoofer System
• RMS power handling: 500W
• Max. power handling: 1000W
• Single 4Ω terminal
Subwoofer Driver
Frequency Response
Sensitivity 1W/m SPL
Normal Impedance
Dimensions (W × H × D)
Weight (Gross)
Weight (Net)
Finish
Continuous Power Handling
Maximum Power Handling
SW5124BX
12˝ Truck-box Subwoofer System
• RMS power handling: 125W
• Max. power handling: 250W
Speaker Grill
SW6124BXD
SW6124 × 2
28 — 250Hz
88dB
8Ω + 8Ω Parallel = 4Ω
27.6˝ × 13.8˝ × 15.3˝ (701 × 350 × 389mm)
51.8lbs (23.5kg)
51.3lbs (23.3kg)
Grey & Black Vinyl
500W
1000W
Cutaway view of the SW5124 Lo-Profile Custom
Application Woofer shows the significantly reduced
depth of this speaker that makes it an ideal choice to
install in a truck-box enclosure.
SW6124BX
12˝ Subwoofer System
• RMS power handling: 250W
• Max. power handling: 500W
SW6124BX
SW6124
28 — 250Hz
85dB
4Ω
14.7˝ × 13.9˝ × 15.3˝ (373 × 353 × 389mm)
30.8lbs (14kg)
30.5lbs (13.9kg)
Grey & Black Vinyl
250W
500W
Speaker Grill
SW5124BX
SW5124
35 — 250Hz
88dB
4Ω
18.9˝ × 15˝ × 8˝ (480 × 381 × 203mm)
26lbs (11.8kg)
25.5lbs (11.6kg)
Grey & Black Vinyl
125W
250W
31
