Eclipse AVN7000 Brochure page 30

Subwoofers
SW7000 Series
SW6000 Series
SW4000 Series
Size
Fs
Qts
DCR
Vas
Xmax (one way)
Continuous Power Handling
Maxmum Power Handling
30
SW7200
SW7000
• RMS power handling: 500W/450W
• Max. power handling: 1500W/1300W
SW6200
SW6000
• RMS power handling: 350W/300W
• Max. power handling: 1000W/900W
SW4200
SW4000
• RMS power handling: 250W/200W
• Max. power handling: 750W/600W
SW7200 SW7000
12˝ 10˝
28Hz 35Hz
0.52 0.58
4Ω + 4Ω 4Ω + 4Ω
2.24 Cuft 0.85 Cuft
0.70˝ 0.70˝
500W 450W
1500W 1300W
SW7000 Series
12˝ Subwoofer (4Ω + 4Ω)
The SW7000 Series incorporates a heatsink
10˝ Subwoofer (4Ω + 4Ω)
voice coil/cone thermal sink that allow
producing 500W without strain. ECLIPSE's low
distortion/high excursion speaker cone design
philosophy lets the speaker travel 1.4 inches,
which is the most in its class.
• Solid aluminum cone heat sink
• Dual 4Ω aluminum voice coil
• Aluminum cast basket
• Rubber magnet boot
• Injection santoprene surround
• Dual conex mirrored spider
Side view of SW7000 Series
• Thruster air vent cooling system
• Vortex design basket heat sink
SW6000 Series
12˝ Subwoofer (4Ω + 4Ω)
A new redesigned SW6000 Series copes with
10˝ Subwoofer (4Ω + 4Ω)
increased input power capability and heavy
duty requirements including a doubling of cone
excursion. The cone material is now a Kevlar
composite, new centralized terminals are
included and the series has a completely new
look that reflects its upgraded performance.
• Kevlar composite cone
• Dual 4Ω aluminum voice coil
• ABS + 15% fiber filled magnet coverd
• Injection santoprene surround
• Rubber gasket
Side view of SW6000 Series
• Flat pc spider
• Air vent cooling system
• Quad 10awg chrome terminal
SW4000 Series
12˝ Subwoofer (4Ω)
The new SW4000 Series easily competes with
10˝ Subwoofer (4Ω)
subwoofers of a higher class. A new Kevlar
composite cone extends lows, maintains rapid
transient response and well-defined pitch.
Distinguished by an attractive and practical grill
design, these speakers offer an ideal solution for
extending system response.
• Kevlar composite cone
• Integrated grill assembly
• Foam surround
• Polycarbonate spider
• 43oz magnet (SW4200), 30oz magnet (SW4000)
Side view of SW4000 Series
• 4-layer aluminum single voice coil
• Air vent cooling system
SW6200 SW6000
12˝ 10˝
31Hz 38Hz
0.77 0.70
4Ω + 4Ω 4Ω + 4Ω
2.0 Cuft 0.85 Cuft
0.03˝ 0.30˝
350W 300W
1000W 900W
SW4200 SW4000
12˝ 10˝
32Hz 38Hz
0.56 0.6
4Ω 4Ω
2.75 Cuft 1.25 Cuft
0.30˝ 0.27˝
250W 200W
750W 600W
