Integrateed Series Speakers
ECLIPSE Integrated Series speakers are
integrated concentric units that are
designed to replace factory speakers for
significantly better music fidelity.
Hybrid Mica PP Cone Woofer
The ECLIPSE speaker cone is hybrid mica PP for
rigidity under intense power, ensuring distortion-
free performance.
Butyl rubber surround
The butyl rubber surround allows linear cone
excursion and dampens cone resonance for
undistorted dynamic peaks and clarity at all
levels.
Kapton voice coil former
Handles a large amount of heat without
deforming.
Tweeter protection
A solid state device protects the speaker system
from power overloads. This device will
momentarily shut down the tweeter circuit, and
will automatically reset when the condition
normalizes.
Super tweeter
(for SE8495, SE8375, SE8365,
SE8355, SE8405 only)
To accommodate the extended high frequency
response of DVD-Audio discs and to provide
superior treble reproduction, the 3-way units
incorporate a newly developed super tweeter that
goes all the way out to 40kHz (typically 50kHz).
Small neodymium tweeter
The use of a neodymium magnet improves
speaker efficiency.
34
SE8495
6 × 9˝ 4-Way
• RMS power handling: 75W
• Max. power handling: 220W
SE8355
5-1/2˝ 3-Way
• RMS power handling: 30W
• Max. power handling: 90W
Size
Frequency Response 50 — 40,000Hz
Sensitivity
Hybrid Mica PP Cone
Rubber Surround
Kapton Voice Coil Former
Midrange Dome
Mylar Tweeter Dome
Super-Tweeter Dome
Neodymium Tweeter Magnet
Ferrite Woofer Magnet
Mounting Depth
SE8375
• RMS power handling: 40W
• Max. power handling: 120W
SE8405
• RMS power handling: 35W
• Max. power handling: 100W
SE8495 SE8375
6 × 9˝ 4-Way 5 × 7˝ 3-Way
85 — 40,000Hz
93dB 90dB
G G
G G
G G
— —
G G
G G
G G
G G
3-1/16˝ 2-1/8˝
5 × 7˝ 3-Way
4 × 10˝ 3-Way
SE8465A
4 × 6˝ 2-Way
105 — 40,000Hz
87dB
G
G
G
—
G
G
G
G
1-3/4˝
