Eclipse AVN7000 Brochure page 13

A VX2494
6.5˝ Wide TFT Touch Panel VGA Display
CD/DVD/MS Multi-Source Receiver with 20GB HDD for Music Juke
Incorporating a 20GB HDD for immense music file storage as well as a
brilliant VGA display, the AVX2494 offers the best of entertainment for
audio and visual program material.
Audio/Visual
20GB HDD
6.5˝ TFT VGA display with touch control
CD/CD-R/RW, MP3
DVD-Video
3,000 track Music Juke
CDDB-enabled
Specifications
14.4V Power Supply
Max. Power Output
Display
Display Resolution
Screen Aspect Ratio
FM Frequency Range
Usable Sensitivity
AM Frequency Range
Usable Sensitivity
CD Frequency Response
Total Harmonic Distortion
Equalizer Parametric: 63Hz — 16kHz±10dB, (25points)
Dimensions (W × H × D) 7˝ × 2˝ × 6-1/2˝ (180 × 50 × 165mm)
Weight
Note: Please refer to iPod Control Function chart on p23 for other AVX models.
'04 Product of the Year
• FM/AM tuner
• High-performance DSP:
5-mode soundfield control
•
9-band GEQ
•
Listening position selector
•
• CD Changer-ready (2 units)
• Memory Stick-ready
• Rear view camera-ready
AVX5000
50W × 4
7˝ wide (16:9), low-glare panel
336,960 dots (480 × 234 × 3)
4 types
15dBf
24µV
20 — 20,000Hz, -2±2dB — 0±2dB
0.03% (0dB, 1kHz)
4.8lbs (2.2kg)
A VX2404
Hi-Power CD/DVD/MS Receiver
with 5.8˝ Touch-Panel TFT Display and MP3/5.1 Decoder
An incredible performer, the AVX2404 is ready to offer any entertainment
required. The most popular audio-dedicated formats as well as DVD-Video
combine with 5.1ch. surround sound for satisfying any entertainment desire.
Audio/Visual
5.8˝ TFT display with touch control
CD/CD-R/RW, MP3
DVD-Video
MOSFET 50W x 4
5.1 ch. surround sound
Multi window
AVX2494
40W × 4
6.5˝ wide (16:9), low-glare panel
1,152,000 dots (800 × 480 × 3)
87.75 — 107.9MHz (200kHz step)
13dBf
530 — 1710kHz (10kHz step)
22µV
20 — 20,000Hz, 1dB
0.03% (0dB, 1kHz)
Graphic: 63Hz — 12kHz, ±10dB
7˝ × 4˝ × 6-1/2˝ (180 × 100 × 165mm)
6.8lbs (3.1kg)
• FM/AM tuner
• Advanced 24-bit ∆∑ DAC
• High-performance DSP:
5-mode soundfield control
•
7-band GEQ
•
Listening position selector
•
• Video input/output
• CD Changer-ready
• Memory Stick-ready
• Rear view camera-ready
• Wallpaper selectable
AVX2404
50W × 4
5.8˝ wide (16:9), low-glare panel
280,800 dots (400 × 234 × 3)
3 types
6.2lbs (2.8kg)
13
