Using the Interface Command

Configuring and Using Interface-Range Macros

You can create an interface-range macro to automatically select a range of interfaces for configuration.
Before you can use the macro keyword in the interface range macro global configuration command
string, you must use the define interface-range global configuration command to define the macro.
Beginning in privileged EXEC mode, follow these steps to define an interface-range macro:
Command
Step 1 configure terminal
Step 2
define interface-range macro_name
interface-range
Step 3 interface range macro macro_name
Step 4 end
Step 5
show running-config | include define
Step 6
copy running-config startup-config
Use the no define interface-range macro_name global configuration command to delete a macro.
When using the define interface-range global configuration command, note these guidelines:
•
•
•
•
Catalyst 2950 Desktop Switch Software Configuration Guide
9-8
Valid entries for interface-range:
vlan vlan-ID - vlan-ID, where VLAN ID is from 1 to 1005 with the SI installed or 1 to 4094
–
with the EI installed
fastethernet slot/{first port} - {last port}, where slot is 0
–
gigabitethernet slot/{first port} - {last port}, where slot is 0
–
– port-channel port-channel-number - port-channel-number, where port-channel-number is
from 1 to 6.
You must add a space between the interface numbers and the hyphen when entering an
interface-range. For example, fastethernet 0/1 - 5 is a valid range; fastethernet 0/1-5 is not a valid
range.
The VLAN interfaces must have been configured with the interface vlan command. The show
running-config privileged EXEC command output shows the configured VLAN interfaces. VLAN
interfaces that do not appear by using the show running-config command cannot be used as
interface-ranges.
All interfaces in a range must be the same type; that is, all Fast Ethernet ports, all Gigabit Ethernet
ports, all EtherChannel ports, or all VLANs, but you can combine multiple interface types in a
macro.
Purpose
Enter global configuration mode.
Define the interface-range macro, and save it in NVRAM.
• The macro_name is a 32-character maximum character string.
• A macro can contain up to five comma-separated interface
ranges. You do not need to enter spaces before or after the comma.
• Each interface-range must consist of the same port type.
Select the interface range to be configured by using the values saved
in the interface-range macro called macro_name.
You can now use the normal configuration commands to apply the
configuration to all interfaces in the defined macro.
Return to privileged EXEC mode.
Show the defined interface-range macro configuration.
(Optional) Save your entries in the configuration file.
Chapter 9 Configuring the Switch Interfaces
