Jumpers
Jumper
JK1, JK2 CPU Bus Frequency Selection
BSEL0, BSEL1
JP3 CPU Ratio Selector
JP5 VIA C3 CPU Selection
JBAT CMOS RAM Clear
Connectors
Connector
POWER
PSKB-MS
USB _ A
LPT
AUD _ GAME
COM1, COM2
FDD
IDE1
IDE2
Headers
Header
USB _ B
IDELED
SMI
PW _ BTN
JP4
WOL
FAN1,FAN2,FAN3
IR
CD _ IN1

Expansion Sockets

Socket/Slot
Zip Socket 370
DIMM1, DIMM2,
DIMM3
PCI1, PCI2, PCI3,
PCI4, PCI5
AGP SLOT
SL1
AMR
Name
Name
ATX Power Connector
PS/2 Keyboard/PS/2 Mouse
USB Port Connector
Parallel Port Connector
Line IN/Line Out/MIC/Game
Connector
Serial Port COMA, COMB
Floppy Driver Connector
Primary IDE Connector
Secondary IDE Connector
Name
USB Port Connector
IDE activity LED
SMI Suspend Switch
ATX power button/soft power button
Front Panel Connector
Wake On LAN
FAN Connector
Infrared Module Connector
CD-Audio
Name
CPU Socket
DIMM Module Socket
PCI Slot
AGP SLOT
ISA Slot
AMR Slot
Description
3-pin Block
2-pin Block
2x4-pin Block
2-pin Block
3-pin Block
Description
20-pin Block
6-pin Female
4-pin Connector
25-pin Female
15-pin Connector+3 phone jack
9-pin Connector
34-pin Block
40-pin Block
40-pin Block
Description
10-pin Block
2-pin Block
2-pin Block
2-pin Block
16-pin Block
3-pin Block
3-pin Block
5-pin Block
4-pin Block
Description
FC-PGA/PPGA CPU Socket
168-pin DIMM SDRAM Module
Expansion Socket
32-bit PCI Local Bus Expansion slots
AGP Expansion Slot
16-bit ISA Bus Expansion slot
Audio Modem Riser Slot
