http://support.intel.com/support/motherboards/server/
WARNING
SHOCK HAZARDS may be present inside the unit in which this card is being installed.
Disconnect all power cords to the unit before removal of any covers. Follow the warnings noted
in the computer's user or service manual before installing this board. ONLY after all the covers
are reinstalled should you reattach the power cords and power up the unit for the software
installation and use.
✏
NOTE
Take precautions to prevent electrostatic discharge (ESD) damage before handling the Intel RAID
Controller SRCU31.
Install the Intel RAID Controller SRCU31 into an available PCI slot. Refer to the board
documentation for details.
1. Shut down and power-off the computer system.
2. Disconnect power cord(s) and remove the system cover.
3. Insert the Intel RAID controller into an available PCI slot.
4. Connect one end of the SCSI cable to the internal (68-pin) or external (VHDCI) SCSI
connector located on the SRCU31 Controller. Connect the other end of the SCSI cable to the
SCSI drives or drive enclosure.
5. Replace the system cover and reconnect power cord(s).
Attach SCSI Cables
1. Connect one end of the SCSI cable to the internal or external SCSI connector located on the
Intel RAID Controller SRCU31.
2. Connect the other end of the SCSI cable to the SCSI drives or drive enclosure.
Programming the FLASH Memory
The Intel RAID Controller SRCU31 normally comes ready to be immediately installed into the
computer server board. However, you may need to reprogram the RAID Firmware that's located in
the flash memory of the Intel RAID Controller SRCU31. Refer to Chapter 7, Firmware Update, for
a normal reprogram of the firmware.
In case the firmware should become corrupted and will not initialize, you will need to recover the
firmware in the flash memory using the Flash Recovery Utility as described in the following
procedure. Firmware updates and the Flash Recovery Utility are available for download from the
Intel support web site at:
http://support.intel.com/support/motherboards/server/
A formatted floppy disk is required for either the firmware update or the Flash Recovery Utility. In
the case of the Flash Recovery Utility, a bootable floppy disk will be created.
Getting Started
25
