8 Storage Console Plus

Introduction

Storage Console Plus (StorCon+) is a tool for setting up, monitoring and maintaining mass storage
subsystems based on Intel RAID Controller SRCU31. Different from StorCon, StorCon+ is a GUI
style application, designed for the operation under Win32 Operating Systems. The primary
function of StorCon+ is to help the user accomplish the following tasks.
Setup Hard Disk Drives Controlled by Intel RAID Controller SRCU31:
•
Setup and initialize physical drives, change the SCSI parameters and cache settings.
•
Easy setup and installation of single disks or array drives consisting of one or more physical
drives (chaining, RAID 0, 1, 4, 5, or 10).
•
Online installation of host drives based on a single disk or an array drive.
Maintenance and Tuning of Existing Array Drives, Host Drives and Intel RAID Controller
SRCU31:
•
Cache Memory Configuration
•
Update the controller firmware
•
Change the device parameters
•
Check or recalculate the parity data of RAID 4 and RAID 5 array drives
•
Online capacity expansion of array drives
•
Split and merge host drives
•
Hot Plug. Replace a failed member of an array drive
•
Hot Fix. Configure a spare disk for an array drive
•
Configure SAF-TE compliant enclosures

Monitoring of the Whole Subsystem

•
Watch the performance and throughput of virtually every part of the subsystem. Simply
drag-and-drop the device on the statistics window.
•
Check the hard disk drives for retries and reassigns (replacements of defective sectors on a hard
disk drive) to trace problems which might become potential in the future.
•
Check the grown defect table of the hard disk drives to replace a defective drive in time.

Remote Configuration and Maintenance

•
Except for the hot plug function, all of the above features can be accessed via network.
You can maintain and monitor a customer's server via the Internet.
•
Supported protocols: IPX/SPX, TCP/IP, NetBIOS.
•
The access to the Intel RAID Controller SRCU31 can be protected by password. The password
is encrypted.
To install the StorCon+, use the Intel RAID Controller SRCU31 tools program on the Intel RAID
Controller SRCU31 System CD-ROM.
123
