Maximum document
batch height for
automatic feeding
Downward and upward
curl documents
Adjusting the side
guides on the input
tray
2-4
When feeding batched documents, the maximum height of the batched
documents is 10.2 cm (4 in.), approximately 1000 sheets of 75g (20 lb.)
paper. The elevator tray can be set to accommodate 25-, 250- 500-, 750-
1000-document stacks.
The elevator tray can handle some amount of lead edge curl, but to
ensure reliable feeding the curl should be at a minimum. It is suggested
that you try and minimize the curl before scanning by stacking the
documents on a flat surface for a period of time to help flatten the
documents.
To accommodate multiple applications with variable feeding
requirements, the side guides can be adjusted for center- or edge-
feeding. Center-feeding is recommended for best paper handling
performance. The side guides can be moved together or independently.
1. Pull the guides all the way out and then push them together (toward
the center) to reset.
2. Open the side guides slightly wider than the documents you will be
feeding.
3. Place the documents in the elevator tray.
4. Adjust the side guides to fit the documents.
A-61169 January 2005
