Server Chassis Features
/
NOTE
I/O ports vary, depending on the server/workstation board installed. See your server board documentation for
port identification.
10
Callout
A Fixed Power Supply
B I/O Ports
C PCI Add-in Card Slots
D PCI Card Latch
E Rear Serial B Connector (optional)
F AC Power Connector

Figure 6. Server Chassis Back

Function
Intel® Server Chassis SC5600 Service Guide
