Media Compartment
EasyCoder PD41: Media Compartment
Print Mechanism
Label taken
sensor
Printhead
balance boxes
Thermal printhead
EasyCoder PD41 Printer User's Guide
Ink position lever
EasyCoder PD41: Print Mechanism
Chapter 1 — Getting Started
Edge guide
Media supply post
Ribbon supply shaft
Ribbon rewind shaft
Tear bar
Ribbon
rod
Media
feed
rods
Printhead
lever
7
