Font Card
CompactFlash Protection Plate
RFID Kit
Special Printheads
8 dots/mm (203.2 dots per inch)
11.81 dots/mm (300 dots per inch)
EasyCoder PM4i Printer User's Guide (Fingerprint Version)
This is a CompactFlash memory card loaded with fonts. With a
Font Card installed, the user gets access to double-byte font sets
including Kanji, Korean and Chinese.
The protection plate encloses an inserted CompactFlash card and
makes it more difficult to steal. See Chapter 3 for illustration.
Can be installed by the operator.
The EasyCoder PM4i can be equipped with the capability to read
and write data to labels fitted with RFID (Radio Frequency
IDentification) inlays. RFID Kits come either factory installed or
as a field-installable option.
As standard, the printer is fitted with an 8 dots/mm (203.2 dots/
in) thermal printhead. There are also a number of optional
printheads for special applications. The printhead can easily be
replaced or exchanged by the operator as described in Chapter
11.
Media Thickness
μ
Max 175
m (7 mils)
μ
170-220
m (6.6-8.7 mils)
μ
170-220
m (6.6-8.7 mils)
3 mm offset
Media Thickness
μ
Max 175
m (7 mils)
μ
170-220
m (6.6-8.7 mils)
Chapter 9 — Options
Standard/Option
Standard
Option
Option
Standard/Option
Option
Option
87
