Chapter 12 — Adjustments
116
In the Print Defines part of the Setup Mode, you can test the
label stop sensor if you have a detection problem; LSS Auto and
LSS Manual.
The menu only provides indications from the label stop sensor
unit. The testing menu can determine if the sensor unit is not
physically in position, is blocked by dust or stuck labels, or is
defective in some way. Furthermore, this is an aid if media has
detection complications.
Note: There is no way to adjust the LSS-function; the menus
only indicate values obtained from the LSS obtained by
performing a TESTFEED operation.
LSS Auto is the quick and normal way to determine if the label
stop sensor works properly and is able to detect gaps, slots, or
black marks.
LSS Manual shows the actual setting provided by the latest
TESTFEED operation. It is also possible to try other settings.
LSS Manual is primarily intended for service and is not described
in this manual.

LSS Auto

• Check that the printer is set up for the type of media loaded
in your printer (Setup Mode
Mark, or Continuous.
• Lift and lower the printhead, then press the Feed/Pause
button.
• Perform a TESTFEED by simultaneously pressing the Shift
and Feed keys on the printer's keyboard.
• Make sure that there is a label—not a gap or mark—at the
LSS.
• Check that the media is routed as close to the center section as
the guides allow.
• Enter the Setup Mode (For help, see "Setup Mode" on
page 69.) and go to Setup Mode
→
Test LSS Auto.
• The menu should look like this with the cursor placed in the
center:
EasyCoder PM4i Printer User's Guide (Fingerprint Version)
→ →
Media Media type
→ →
Test/Service
→
Gap,
LSS
