EasyCoder PM4i Printer User's Guide (Fingerprint Version)
LSS Auto
• Gap or slot detection:
Lift the printhead and pull out the media slowly. When the
LSS detects a gap or a detection slot, the cursor moves to the
right.
LSS Auto
• Black Mark detection:
Lift the printhead and pull out the media slowly. When the
LSS detects a black mark, the cursor moves to the left.
LSS Auto
It is possible to refresh the centered cursor position by pressing
/F4
the key.
• If the cursor behaves as described above, the LSS is working
and is properly aligned with the gaps, slots, or black marks.
• If the cursor does not react on a gap, slot, or black mark,
check this:
• Is the LSS laterally aligned with the slots or black marks?
• Are both the upper and lower part of the LSS aligned with
each other?
• Is the transfer ribbon properly loaded so it does not
interfere with the LSS? For help, see "Thermal Transfer
Printing" on page 43.
• Are the LSS guides clean and free from stuck labels or
other objects that will interfere with the light that goes
from one part of the LSS to the other? If not, clean as
described in Chapter 10.
• Does the media have some kind of preprint that can
disturb the detection?
• Is there too little difference between the black marks and
the surrounding areas?
• Does the liner have too little transparency?
Chapter 12 — Adjustments
117
