3-2 System Settings
N o t
N o t
N o t
Saved $HB/$HW status and each logging data will be automatically read when the NS-
Runtime starts up next time.
A folder specified as a save destination of history data is used in the following purposes as
well.
-Destination to save BMP files created by $SB25(Screen capture).
-Destination to save data files to be used for data blocks (When the Memory Card is selected
as a destination to read/write data files).
-Destination to save files specified with READCF/WRITECF macro.
Even when the Set the 'save cycle for Internal Holding Memory' is specified, $HB, $HW and
history data will be saved when the NS-Runtime ends.
3-2-4

Printer Tab Page

There is no Printer Tab with an NS-Runtime project, because a printer set with Windows will
be used.
3-2-5

Video Tab Page

There is no Video Tab because the NS-Runtime does not support video display.
3-2-6

Maximum Screen Size Tab Page

Setting the NS-Runtime main window size in the Maximum Screen Size.
Use this function when using the NS-Runtime in non-NSA Series environments.
3-8
