System Word Memory ($SW)

System word memory ($SW) is used to exchange information between the host and NS-
Runtime in word units, such as for controlling the NS-Runtime and notifying the status.
The system word memory contains 41 items with predefined functions.
The system word memory is listed in the following table.
Address
$SW0
$SW1
$SW2
$SW3
$SW4
$SW5
$SW6
$SW7
$SW8
$SW9
$SW10
$SW11
$SW12
$SW13
$SW14
$SW15
$SW16
$SW17
$SW18
$SW19
$SW20
$SW21
$SW22
$SW23
$SW24
$SW25
$SW26
$SW27
$SW28
$SW29
$SW30
$SW31
$SW32
$SW33
$SW34
Classification
Notification/control
Notification/control
Notification/control
Notification/control
Notification/control
Notification/control
Notification/control
Notification/control
Notification/control
Notification/control
Notification/control
Control
-
Control
Notification
Notification
Notification
Notification
Notification
Notification
Notification
Notification
-
Notification
Notification
Notification
Notification
Control
Control
Control
Control
Control
Control
Control
Control
Function
Current Screen No.
Current Pop-up Screen 1 No.
Position of Pop-up Screen 1 (X
Coordinate)
Position of Pop-up Screen 1 (Y
Coordinate)
Current Pop-up Screen 2 No.
Position of Pop-up Screen 2 (X
Coordinate)
Position of Pop-up Screen 2 (Y
Coordinate)
Current Pop-up Screen 3 No.
Position of Pop-up Screen 3 (X
Coordinate)
Position of Pop-up Screen 3 (Y
Coordinate)
Current Label No.
Destination(0:Printer, 1:Memory
Card)
Reserved
Password Number for Canceling
Input Prohibition
Current Time (min, s)
Current Date and Time (Day, Hour)
Current Date and Time (Year,
Month)
Current Day (Day of the Week)
No. of Generated Alarms and Events
Generated Alarm/Event ID No.
Cancelled Alarm/Event ID No.
Alarm/Event ID of Executed
Alarm/Event Object Macro
Reserved
Macro Error No.
Macro Error Screen No.
Macro Error Object ID No.
Error Macro Execution Timing
Offset Value for Index I0
Offset Value for Index I1
Offset Value for Index I2
Offset Value for Index I3
Offset Value for Index I4
Offset Value for Index I5
Offset Value for Index I6
Offset Value for Index I7
4-1 System Memory
Non-
NSA
NSA
Series
Series
OK OK
OK OK
OK OK
OK OK
OK OK
OK OK
OK OK
OK OK
OK OK
OK OK
OK OK
OK OK
- -
OK OK
OK OK
OK OK
OK OK
OK OK
OK OK
OK OK
OK OK
OK OK
- -
OK OK
OK OK
OK OK
OK OK
OK OK
OK OK
OK OK
OK OK
OK OK
OK OK
OK OK
OK OK
